331-1375 AXLE & TRANSMISSION ARS/N FB41-UP

Group No: 331-1375
Part NumberPart NameQty
41619171 TRANSMISSION GP1
33380392 HOUSING-AXLE2
33380403 SHAFT-AXLE2
23387384 HOUSING1
05465145 SHIM (0.1-MM THK)2
1217679SHIM (0.15-MM THK)2
0546513SHIM (0.2-MM THK)2
1217680SHIM (0.25-MM THK)2
0546512SHIM (0.3-MM THK)2
1287675SHIM (0.35-MM THK)2
7T0564SHIM (0.4-MM THK)2
1217677SHIM (0.45-MM THK)2
7T0563SHIM (0.5-MM THK)2
1217678SHIM (0.55-MM THK)2
7T0562SHIM (0.6-MM THK)2
1287676SHIM (0.65-MM THK)2
1287677SHIM (0.7-MM THK)2
1287680SHIM (0.75-MM THK)2
7T0561SHIM (0.8-MM THK)2
1287681SHIM (0.85-MM THK)2
1287683SHIM (0.9-MM THK)2
1287684SHIM (0.95-MM THK)2
7T0560SHIM (1-MM THK)2
1287685SHIM (1.05-MM THK)2
1287686SHIM (1.1-MM THK)2
1287687SHIM (1.15-MM THK)2
1287688SHIM (1.25-MM THK)2
1287689SHIM (1.3-MM THK)2
1287690SHIM (1.35-MM THK)2
7T0558SHIM (1.4-MM THK)2
1287691SHIM (1.45-MM THK)2
1287692SHIM (1.5-MM THK)2
1287693SHIM (1.55-MM THK)2
1287694SHIM (1.6-MM THK)2
1287695SHIM (1.65-MM THK)2
7T0552SHIM (2-MM THK)2
2028137SHIM (1.47-MM THK)2
2028138SHIM (1.63-MM THK)2
2028139SHIM (1.75-MM THK)2
2028140SHIM (1.7-MM THK)2
2028141SHIM (1.8-MM THK)2
2028142SHIM (1.85-MM THK)2
2028143SHIM (1.9-MM THK)2
2028144SHIM (1.95-MM THK)2
6Y294245 BEARING-TAPERED ROLLER2
6Y294346 CUP-BEARING (TAPERED ROLLER)2
8U607947 SEAL-O-RING2
5W562748 BOLT (M18X2.5X60-MM)32
263362949 PLUG AS3
203021549A SEAL-O-RING1
203021550 SEAL-O-RING1
263363051 PLUG AS-MAGNET (AXLE HOUSING)1
8T418352 BOLT (M12X1.75X40-MM)4
6V814953 NUT (M12X1.75-THD)10
372412054 GEAR-CROWN1
371732855 CASE-DIFFERENTIAL1
331139156 COVER1
331139358 WASHER-THRUST2
416231959 GEAR-DIFFERENTIAL2
331139660 GEAR-DIFFERENTIAL4
331139761 WASHER-THRUST4
331139862 SHAFT1
331139963 SHAFT2
204397564 PIN-SPRING2
336737765 BOLT-SOCKET HEAD (M12X1.5X35-MM)16
270309666 HUB GP-WHEEL2
268878266A NUT-SPANNER (M30X1.5-THD)1
5W568267 VALVE AS-PURGE (AXLE)2
8T414068 BOLT (M16X2X60-MM)28
270687169 SEAL-O-RING2
384987370 GEAR-SUN2
130687971 SEAL2
2S048072 CUP-TAPERED ROLLER2
178860873 CONE-TAPERED2
333803874 GEAR-CARRIER2
7X576275 SEAL-O-RING2
333802876 HUB-FLANGE2
267898577 SEAL-O-RING4
267898478 SEAL-O-RING2
316789879 GEAR-INTERNAL2
328880380 PISTON2
263405781 DOWEL6
121763982 RING2
121763783 RING-BACKUP2
267916684 SEAL2
267916785 RING2
8U359286 SPRING12
238330587 SPRING12
298231588 BOLT-SPECIAL12
8U359189 SPACER (6.5X15X7-MM THK)12
267916890 DISC-CLUTCH16
267917091 DISC-CLUTCH16
2679169DISC-CLUTCH4
2679171DISC-CLUTCH4
375136094 WASHER-THRUST (10X40.2X5.1-MM THK)2
375826395 CAGE-PINION2
386382296 GEAR-PLANETARY6
095092498 RING-RETAINING6
6V366899 BOLT (M12X1.75X30-MM)4
2435336100 BOLT (M10X1.5X20-MM)2
2679161101 BEARING-TAPERED ROLLER2
3338037102 STUD-WHEEL20
