331-1370 AXLE GP-STEERINGS/N FB41-UP

Group No: 331-1370
Part NumberPart NameQty
37241201 GEAR-CROWN1
37241232 PINION1
11001243 SHIM (2-MM THK)1
1100122SHIM (1.8-MM THK)1
1100121SHIM (1.5-MM THK)1
1100120SHIM (1.2-MM THK)1
1299912SHIM (1.9-MM THK)1
1299913SHIM (1.7-MM THK)1
1299914SHIM (1.6-MM THK)1
1299915SHIM (1.4-MM THK)1
1299916SHIM (1.3-MM THK)1
1908567SHIM (1-MM THK)1
1908566SHIM (0.9-MM THK)1
1908565SHIM (0.8-MM THK)1
1908563SHIM (0.7-MM THK)1
1908561SHIM (0.6-MM THK)1
5W2074SHIM (0.5-MM THK)1
5W2073SHIM (0.3-MM THK)1
5W3644SHIM (0.2-MM THK)1
5W2072SHIM (0.1-MM THK)1
1931123SHIM (0.75-MM THK)1
1931124SHIM (0.65-MM THK)1
3311378SHIM (1.25-MM THK)1
3311379SHIM (1.35-MM THK)1
3311381SHIM (1.45-MM THK)1
3311382SHIM (1.55-MM THK)1
3311383SHIM (1.65-MM THK)1
3311384SHIM (1.75-MM THK)1
3311386SHIM (1.85-MM THK)1
333804830 BEARING-TAPERED ROLLER1
110015831 RING (16-MM THK)1
4900441RING (16.1-MM THK)1
1100156RING (16.2-MM THK)1
1100155RING (16.3-MM THK)1
1100154RING (16.4-MM THK)1
1100153RING (16.5-MM THK)1
1100152RING (16.6-MM THK)1
1100151RING (16.7-MM THK)1
4900458RING (16.8-MM THK)1
1100146RING (16.92-MM THK)1
1100139RING (17.2-MM THK)1
4907393RING (17.3-MM THK)1
4907394RING (17.4-MM THK)1
4206082RING (16.9-MM THK)1
1100144RING (16.98-MM THK)1
4371494RING (17.04-MM THK)1
2029635RING (16.56-MM THK)1
2029636RING (16.62-MM THK)1
2029637RING (16.64-MM THK)1
2029643RING (16.68-MM THK)1
2029644RING (16.72-MM THK)1
2029669RING (16.74-MM THK)1
2029670RING (16.76-MM THK)1
2029671RING (16.78-MM THK)1
2029672RING (16.82-MM THK)1
2029673RING (16.84-MM THK)1
2029679RING (16.88-MM THK)1
2029680RING (16.9-MM THK)2
2029681RING (16.94-MM THK)1
1931454RING (16.66-MM THK)1
4907374RING (16.96-MM THK)1
1931458RING (17-MM THK)1
1931460RING (17.02-MM THK)1
4736651RING (17.06-MM THK)1
1931462RING (17.08-MM THK)1
1931463RING (17.12-MM THK)1
1931464RING (17.14-MM THK)1
1931465RING (17.16-MM THK)1
1931466RING (17.18-MM THK)1
1931467RING (17.22-MM THK)1
1931469RING (17.24-MM THK)1
1931470RING (17.26-MM THK)1
1931471RING (17.28-MM THK)1
269240775 BEARING-ROLLER1
418861676 SEAL-LIP TYPE1
8U250677 WASHER (30.5X55.5X6-MM THK)1
110084878 NUT (M30X1.5-THD)1
417666079 FLANGE-DRIVE1
331138880 PLATE-DEFLECTOR1
519701881 CASE-DIFFERENTIAL1
331139182 COVER1
331139384 WASHER-THRUST2
416231985 GEAR-DIFFERENTIAL2
331139686 GEAR-DIFFERENTIAL4
331139787 WASHER-THRUST4
331139888 SHAFT1
519701989 SHAFT2
2M352190 PIN-SPRING2
336737791 BOLT-SOCKET HEAD (M12X1.5X35-MM)16
054651492 SHIM (0.1-MM THK)2
1217679SHIM (0.15-MM THK)2
0546513SHIM (0.2-MM THK)2
1217680SHIM (0.25-MM THK)2
0546512SHIM (0.3-MM THK)2
1287675SHIM (0.35-MM THK)2
7T0564SHIM (0.4-MM THK)2
1217677SHIM (0.45-MM THK)2
7T0563SHIM (0.5-MM THK)2
1217678SHIM (0.55-MM THK)2
7T0562SHIM (0.6-MM THK)2
1287676SHIM (0.65-MM THK)2
1287677SHIM (0.7-MM THK)2
1287680SHIM (0.75-MM THK)2
7T0561SHIM (0.8-MM THK)2
1287681SHIM (0.85-MM THK)2
1287683SHIM (0.9-MM THK)2
1287684SHIM (0.95-MM THK)2
7T0560SHIM (1-MM THK)2
1287685SHIM (1.05-MM THK)2
1287686SHIM (1.1-MM THK)2
1287687SHIM (1.15-MM THK)2
1287688SHIM (1.25-MM THK)2
1287689SHIM (1.3-MM THK)2
1287690SHIM (1.35-MM THK)2
7T0558SHIM (1.4-MM THK)2
1287691SHIM (1.45-MM THK)2
1287692SHIM (1.5-MM THK)2
1287693SHIM (1.55-MM THK)2
1287694SHIM (1.6-MM THK)2
1287695SHIM (1.65-MM THK)2
7T0552SHIM (2-MM THK)2
2028137SHIM (1.47-MM THK)2
2028138SHIM (1.63-MM THK)2
2028139SHIM (1.75-MM THK)2
2028140SHIM (1.7-MM THK)2
2028141SHIM (1.8-MM THK)2
2028142SHIM (1.85-MM THK)2
2028143SHIM (1.9-MM THK)2
2028144SHIM (1.95-MM THK)2
6Y2942133 BEARING-TAPERED ROLLER2
6Y2943134 CUP-BEARING (TAPERED ROLLER)2
8U6079135 SEAL-O-RING2
5W5627136 BOLT (M18X2.5X60-MM)32
2633629137 PLUG AS3
2030215SEAL-O-RING1
2030215138 SEAL-O-RING1
2633630139 PLUG AS-MAGNET (AXLE HOUSING)1
2030215SEAL-O-RING1
3311408140 HOUSING-AXLE2
3311409141 HOUSING1
8U2353142 BUSHING4
4858328143 SEAL-SHAFT4
3882516144 BUSHING2
3723536145 UNIVERSAL JOINT GP2
2718866FORK1
2718867SPIDER2
2430909146 TIE ROD GP (LH)1
2430911147 TIE ROD GP (RH)1
2956358NUT (M28X1.5-THD)1
2430910BALL JOINT AS1
1645912148 LOCKNUT (M27X1.5-THD)2
5176703149 HOUSING GP-AXLE (LH)1
5176701150 HOUSING GP-AXLE (RH)1
2688782NUT-SPANNER (M30X1.5-THD)1
3338047151 BEARING-TAPERED ROLLER4
5W5466152 CAP-BEARING4
1148837153 SEAL-O-RING4
3338021154 TRUNNION2
1353437155 SEAL-O-RING4
3145416156 BOLT-SPECIAL16
3338022157 TRUNNION2
5W2998158 FITTING-GREASE4
2679159161 WASHER-THRUST2
2679160162 WASHER-THRUST2
2733142163 RING2
5W5682164 VALVE AS-PURGE (AXLE)2
8U2354165 SHIM (6-MM THK)2
5W6405SHIM (6.5-MM THK)2
5W7644SHIM (4-MM THK)2
5W7642SHIM (5-MM THK)2
5W7641SHIM (5.5-MM THK)2
5W7643SHIM (4.5-MM THK)2
1281733SHIM (2-MM THK)2
1281734SHIM (3-MM THK)2
5W6408WASHER (18.5X35X8-MM THK)2
2028145WASHER (18.5X35X9-MM THK)2
2028149WASHER (18.5X35X14-MM THK)2
5W2173176 BOLT (M18X2.5X40-MM)4
2418122177 NUT (M18X2.5-THD)2
3751285178 CYLINDER GP-STEERING1
6V3823179 BOLT (M12X1.75X60-MM)5
1306879180 SEAL2
2S0480181 CUP-TAPERED ROLLER2
2679161182 BEARING-TAPERED ROLLER2
3338028183 HUB-FLANGE2
7X5762184 SEAL-O-RING2
3338038185 GEAR-CARRIER2
2678985186 SEAL-O-RING4
2678984187 SEAL-O-RING2
3167898188 GEAR-INTERNAL2
3288803189 PISTON2
2634057190 DOWEL6
1217639191 RING (3.6-MM THK)2
1217637192 RING-BACKUP2
2679166193 SEAL2
2679167194 RING (2-MM THK)2
8U3592195 SPRING12
2383305196 SPRING12
2982315197 BOLT-SPECIAL12
8U3591198 SPACER (6.5X15X7-MM THK)12
2679168199 DISC-CLUTCH16
2679170200 DISC-CLUTCH16
2679169DISC-CLUTCH4
2679171DISC-CLUTCH4
3751360203 WASHER-THRUST (10X40.2X5.1-MM THK)2
3758263204 CAGE-PINION2
3863822205 GEAR-PLANETARY6
0950924207 RING-RETAINING6
6V3668208 BOLT (M12X1.75X30-MM)4
2435336209 BOLT (M10X1.5X20-MM)2
3338037210 STUD-WHEEL20
1788608211 CONE-TAPERED2
