System And Components
274-4578 SHAFT GP-INPUTS/N DC91-UP
Group No: 274-4578
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2949812 | 1 RETAINER-SPRING | 2 | |
| 6V8757 | 3 RING-RETAINING | 3 | |
| 6Y7929 | 4 DISC-FRICTION | 11 | |
| 7T6655 | 5 BEARING | 2 | |
| 8E5707 | 6 PLATE-END | 2 | |
| 9U8886 | 7 RING-SEAL | 4 | |
| 1210694 | 8 WASHER-THRUST (40X70X4-MM THK) | 1 | |
| 1212500 | 9 WASHER-THRUST (50X70X4-MM THK) | 3 | |
| 1221886 | 10 RING-SEAL | 1 | |
| 3888330 | 11 BEARING AS-TAPERED ROLLER | 1 | |
| 1238905 | CONE-BEARING | 1 | |
| 1238906 | CUP-TAPERED ROLLER | 1 | |
| 3499891 | 13 BEARING-TAPERED ROLLER | 1 | |
| 1238913 | 15 BEARING-ROLLER | 2 | |
| 1470202 | 16 GEAR (45/24-TEETH) | 1 | |
| 1470224 | 17 GEAR (45/32-TEETH) | 1 | |
| 5582827 | 18 PISTON-CLUTCH | 2 | |
| 1470238 | 19 SPRING AS | 2 | |
| 1470257 | 20 SHAFT AS-INPUT | 1 | |
| 1230714 | 20A BEARING | 1 | |
| 1232920 | PLUG | 3 | |
| 1470259 | 21 SPACER (51.1X54.9X18.7-MM THK) | 1 | |
| 1725317 | 22 BEARING-SPECIAL | 4 | |
| 2744553 | 23 DISC-CLUTCH | 11 | |
| 9U8875 | 24 RING-RETAINING | 2 |
