Assembly
100%

445-0027 STICK GP-EXTENDABLES/N H8W1-UP

Group No: 445-0027
Part NumberPart NameQty
09579501 RING-RETAINING2
1L37682 RING-RETAINING2
4F87113 PLUG-BUTTON2
3B84884 FITTING-GREASE (1/8-27 PTF)1
3B84895 FITTING-GREASE (1/8-27 PTF)5
11564336 WASHER (11X50X6-MM THK)4
6V43647 RING-RETAINING2
6V83448 RING-RETAINING2
8T41219 WASHER-HARD (11X21X2.5-MM THK)14
8T413610 BOLT (M10X1.5X25-MM)2
8T413911 BOLT (M12X1.75X30-MM)2
8T418312 BOLT (M12X1.75X40-MM)2
8T419413 BOLT (M12X1.75X50-MM)2
8T419514 BOLT (M10X1.5X30-MM)2
8T422315 WASHER-HARD (13.5X25.5X3-MM THK)26
8T491016 BOLT (M12X1.75X60-MM)4
9R048117 WASHER (71X110X4-MM THK)4
9R151018 WASHER (51X82X4-MM THK)3
9R295919 CLIP2
9R523820 SPACER (56X110X3-MM THK)6
111925121 WASHER-HARD (20X35X1.6-MM THK)2
209243522 BLOCK2
213671823 PIN1
214614324 PIN1
216629525 PLATE1
217005526 PIN1
217157727 PAD AS2
220101828 PIN1
220101929 PIN1
220710830 WASHER (51X85X1-MM THK)2
222517131 SCREW AS (ADJUSTER)2
3E4352WASHER-HARD (8.8X20.5X2.5-MM THK)1
9X2403SETSCREW-HEX SOCKET (M12X1.75X50-MM)1
223392632 PLATE1
226976433 PAD AS2
311807534 PLATE4
233516635 SHIM (1-MM THK)16
2335167SHIM (2-MM THK)4
233516937 PAD4
259180238 FILM-INSTRUCTION (EXTENDABLE STICK PIN, READ OMM)2
287566739 SHIM (1-MM THK)6
293988240 SHIM (1-MM THK)8
2939884SHIM (0.25-MM THK)8
445003742 STICK AS (INNER)1
213671542A BUSHING2
445003943 STICK AS (OUTER)1
9R016243A BUSHING2
286716643B BUSHING1
1076711BLOCK2
8C899244 BOLT-LOCKING (M12X1.75X30-MM)16
