System And Components
313-1380 HOUSING GP-FRONTS/N CRS1-UP
Group No: 313-1380
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3460408 | 1 PLATE | 1 | |
| 6I0217 | 2 BOLT (M8X1.25X20-MM) | 6 | |
| 6I0645 | 3 BOLT (M8X1.25X25-MM) | 4 | |
| 6I0650 | 4 BOLT (M10X1.5X65-MM) | 3 | |
| 7C4616 | 5 BOLT (M12X1.75X45-MM) | 1 | |
| 0676179 | 6 DOWEL | 1 | |
| 1003751 | 7 BOLT (M8X1.25X65-MM) | 5 | |
| 1243815 | 8 BOLT (M8X1.25X16-MM) | 10 | |
| 1331011 | 9 WASHER | 1 | |
| 2168634 | 10 GEAR-CAMSHAFT (68-TEETH) | 1 | |
| 2323657 | 11 COVER AS-FRONT | 1 | |
| 2258287 | 11A GASKET | 1 | |
| 2323666 | 12 WASHER-THRUST | 1 | |
| 2514336 | 13 GEAR AS-IDLER (73-TEETH) | 1 | |
| 2773012 | 14 GASKET-COVER (HOUSING) | 1 | |
| 3240444 | 15 HUB-IDLER GEAR | 1 | |
| 2880422 | 16 SEAL-CRANKSHAFT | 1 | |
| 2940288 | 17 HOUSING-FRONT | 1 | |
| 1013895 | 18 BOLT (M8X1.25X35-MM) | 2 |
