Assembly
100%

214-6080 STICK GP-EXTENDABLES/N LBE1-UP

Group No: 214-6080
Part NumberPart NameQty
3B84891 FITTING-GREASE (1/8-27 PTF)4
9R29592 CLIP2
20924353 BLOCK2
21070984 CYLINDER GP-EXTENDABLE STICK (EXTENDABLE)1
30583875 STICK AS (INNER)1
21367195A BUSHING2
21367155B BUSHING2
21436396 STICK AS (OUTER)1
28671666A BUSHING2
9R01626B BUSHING2
21461437 PIN1
21662958 PLATE1
21700559 PIN1
217157710 PAD AS1
220101811 PIN1
222517112 SCREW AS (ADJUSTER)2
223392613 PLATE1
226976414 PAD AS2
233516515 PLATE4
233516616 SHIM (1-MM THK)12
233516717 SHIM (2-MM THK)4
233516918 PAD4
247326819 LINES GP-EXTENDABLE STICK1
1L376820 RING-RETAINING2
4F871121 PLUG-BUTTON2
5V719022 WASHER-HARD (10.5X45.2X6-MM THK)4
6V436423 RING-RETAINING2
8T412124 WASHER-HARD (11X21X2.5-MM THK)12
8T413625 BOLT (M10X1.5X25-MM)2
8T413926 BOLT (M12X1.75X30-MM)2
8T418327 BOLT (M12X1.75X40-MM)2
8T419428 BOLT (M12X1.75X50-MM)2
8T419529 BOLT (M10X1.5X30-MM)2
8T422330 WASHER-HARD (13.5X25.5X3-MM THK)26
8T491031 BOLT (M12X1.75X60-MM)4
284361532 SCREW-HEX SOCKET (M12X1.75X35-MM)16
287566733 SHIM (1-MM THK)6
289942634 PAD AS1
095120735 NUT (M12X1.75-THD)2
7X060336 WASHER-HARD (9.9X35X2.5-MM THK)2
