System And Components
1W-8899 LINES GP-TURBOCHARGER OILS/N 2FG7200-UP
Group No: 1W-8899
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1408428 | 1 TUBE AS | 1 | |
| 1S7057 | 2 GASKET | 1 | |
| 6V3940 | 3 BOLT (M8X1.25X25-MM) | 4 | |
| 9M1974 | 4 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 7W2398 | 5 GASKET (OIL DRAIN) | 1 | |
| 7C0913 | 6 CLIP (SLOT) | 1 | |
| 7C0912 | 7 CLIP (TAB) | 1 | |
| 1468133 | 8 TUBE AS | 1 | |
| 6V5217 | 9 BOLT (M8X1.25X20-MM) | 1 | |
| 5P7970 | 10 NUT (M8X1.25-THD) | 1 | |
| 9M4849 | 11 SEAL-O-RING | 1 | |
| 4F7391 | 12 SEAL-O-RING | 1 | |
| 6V5218 | 13 BOLT (M8X1.25X35-MM) | 2 | |
| 1192942 | 14 ADAPTER | 1 | |
| 6V8724 | 15 ELBOW | 1 | |
| 6V8397 | 15A SEAL-O-RING | 1 | |
| 3J1907 | 15B SEAL-O-RING | 1 |
