System And Components
334-3757 HOUSING GP-FRONTS/N CRS1-58772
Group No: 334-3757
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B8736 | 1 KEY-WOODRUFF | 1 | |
| 6I0217 | 2 BOLT (M8X1.25X20-MM) | 6 | |
| 6I0645 | 3 BOLT (M8X1.25X25-MM) | 4 | |
| 6I0650 | 4 BOLT (M10X1.5X65-MM) | 3 | |
| 7C4616 | 5 BOLT (M12X1.75X45-MM) | 1 | |
| 0676179 | 6 DOWEL | 1 | |
| 1003751 | 7 BOLT (M8X1.25X65-MM) | 5 | |
| 1013895 | 8 BOLT (M8X1.25X35-MM) | 2 | |
| 1243815 | 9 BOLT (M8X1.25X16-MM) | 10 | |
| 1331011 | 10 WASHER | 1 | |
| 2168634 | 11 GEAR-CAMSHAFT (68-TEETH) | 1 | |
| 2323657 | 12 COVER AS-FRONT | 1 | |
| 2258287 | 12A GASKET | 1 | |
| 2323666 | 13 WASHER-THRUST | 1 | |
| 2514336 | 14 GEAR AS-IDLER (73-TEETH) | 1 | |
| 2773012 | 15 GASKET-COVER | 1 | |
| 2880422 | 16 SEAL-CRANKSHAFT | 1 | |
| 2940288 | 17 HOUSING-FRONT | 1 | |
| 2951711 | 18 PLATE-RETAINING | 1 | |
| 3240444 | 19 HUB-IDLER GEAR | 1 |
