System And Components
209-6860 FRAME GP-SWINGS/N PCR1-UP
Group No: 209-6860
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4821 | 1 WASHER (13.5X40X3-MM THK) | 1 | |
| 8T4837 | 2 WASHER (48X85X6-MM THK) | 1 | |
| 3005440 | 3 PIN | 1 | |
| 9R5429 | 4 SPACER (67.5X120X3-MM THK) | 2 | |
| 9R7882 | 5 SPACER (14X25X7-MM THK) | 1 | |
| 9R8291 | 6 SPACER (66X125X1-MM THK) | 2 | |
| 1302533 | 7 PIN | 2 | |
| 2705290 | 8 BOLT-SOCKET HEAD (M12X1.75X300-MM) | 1 | |
| 2096855 | 9 PIN | 2 | |
| 3165176 | 10 FRAME AS (SWING) | 1 | |
| 9R0366 | 10A WASHER (80X140X5-MM THK) | 1 | |
| 2136702 | 10B BUSHING | 4 | |
| 2368158 | 10C BUSHING | 2 | |
| 2627043 | 10D BEARING | 2 | |
| 2785455 | 10E BUSHING | 2 | |
| 2136709 | 11 PIN AS | 1 | |
| 3288776 | 12 PIN AS | 1 | |
| 2487385 | 13 LUG | 1 | |
| 1367440 | 14 SHIM (1-MM THK) | 1 | |
| 3B8488 | 15 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 3B8489 | 16 FITTING-GREASE (1/8-27 PTF) | 3 | |
| 6V7687 | 17 LOCKNUT (M12X1.75-THD) | 4 | |
| 8T3652 | 18 NUT (M42X2-THD) | 1 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4821 | 20 WASHER (13.5X40X3-MM THK) | 3 | |
| 8T5041 | 21 BOLT (M12X1.75X120-MM) | 1 | |
| 8T7930 | 22 BOLT (M12X1.75X160-MM) | 2 | |
| 5P1076 | 23 WASHER-HARD (13.5X30X4-MM THK) | 3 |
