System And Components
257-3920 LINES GP-RIDE CONTROLS/N PCR1-UP
Group No: 257-3920
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 3 | |
| 1623960 | 2 ACCUMULATOR GP-RIDE CONTROL (CHARGED) | 1 | |
| 1417684 | 3 HOSE AS | 1 | |
| 2458780 | 4 MANIFOLD GP-RIDE CONTROL | 1 | |
| 2470320 | 5 BRACKET AS | 1 | |
| 2521221 | 6 HOSE AS | 1 | |
| 2650868 | 7 HOSE AS | 1 | |
| 2928222 | 8 TUBE AS | 1 | |
| 0965866 | 9 BOLT (M8X1.25X75-MM) | 2 | |
| 1091633 | 10 CLIP (SLOT) | 2 | |
| 1091634 | 11 CLIP (TAB) | 2 | |
| 1488340 | 12 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488354 | 13 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488358 | 14 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8624 | ELBOW | 1 | |
| 1488365 | 15 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 1488370 | 16 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1536241 | 17 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8C8989 | ELBOW | 1 | |
| 2762334 | 18 FILM-WARNING (HIGH PRESS CYLINDER, READ OMM) | 1 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 21 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 23 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4139 | 24 BOLT (M12X1.75X30-MM) | 2 |
