System And Components
297-1030 MUFFLER GP -TURBOS/N MXB1-UP
Group No: 297-1030
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0364 | 1 STUD (M10X1.5X45-MM) | 3 | |
| 6I0563 | 2 NUT (M10X1.5-THD) | 3 | |
| 2985699 | 3 PLATE AS | 1 | |
| 3004485 | 4 MUFFLER AS | 1 | |
| 3044414 | 5 CLAMP AS-MUFFLER | 2 | |
| 3164868 | 6 PLATE AS | 1 | |
| 3229135 | 7 PLATE AS | 1 | |
| 5P4116 | 8 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7X7729 | 9 WASHER (11X25X3-MM THK) | 6 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4133 | 11 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 10 | |
| 8T4908 | 14 BOLT (M8X1.25X25-MM) | 2 |
