System And Components
246-9802 LINES GP-RIDE CONTROLS/N SWC1-528
Group No: 246-9802
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 3 | |
| 1623960 | 2 ACCUMULATOR GP-RIDE CONTROL (CHARGED) | 1 | |
| 2795016 | 3 FILM-WARNING (HIGH PRESS CYLINDER, READ OMM)(U.S.) | 1 | |
| 2762334 | FILM-WARNING (HIGH PRESS CYLINDER, READ OMM)(INTERNATIONAL) | 1 | |
| 2458780 | 4 MANIFOLD GP-RIDE CONTROL | 1 | |
| 2470320 | 5 BRACKET AS | 1 | |
| 2521221 | 6 HOSE AS | 1 | |
| 2650868 | 7 HOSE AS | 1 | |
| 0965866 | 8 BOLT (M8X1.25X75-MM) | 2 | |
| 1091633 | 9 CLIP (SLOT) | 2 | |
| 1091634 | 10 CLIP (TAB) | 2 | |
| 1488340 | 12 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488358 | 13 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8624 | ELBOW | 1 | |
| 1536241 | 14 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8C8989 | ELBOW | 1 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 17 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4139 | 18 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 2928222 | 21 TUBE AS | 1 | |
| 1488365 | 22 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 1488354 | 23 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488370 | 24 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1944334 | 25 HOSE AS | 1 |
