System And Components
375-9570 FAN GP-SUCTION -WITH AIR CONDITIONERS/N LDY1-281
Group No: 375-9570
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3779087 | 1 BELT TENSIONER | 1 | |
| 2610428 | 2 PULLEY AS-IDLER | 1 | |
| 3072242 | BOLT (M10X1.5X45-MM) | 1 | |
| 2841026 | 3 PULLEY (8-GROOVE) | 1 | |
| 3900536 | 4 BELT-SERPENTINE (FAN PULLEY) | 1 | |
| 3488149 | 5 PLATE-MOUNTING | 1 | |
| 3528358 | 6 GUARD AS-FAN | 1 | |
| 4488167 | 7 FILM-INFORMATION (BELT ROUTING) | 1 | |
| 3745381 | 8 SPIDER AS-FAN (9-BLADE) | 1 | |
| 3792197 | 9 SPACER-FAN | 1 | |
| 1783336 | 10 NUT-HEX FLANGE (M8X1.25-THD) | 4 | |
| 3429920 | 11 BOLT-FLANGE HEAD (M8X1.25X20-MM) | 4 | |
| 5P4116 | 12 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4196 | 14 BOLT (M10X1.5X35-MM) | 3 | |
| 8T4224 | 15 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T7547 | 16 BOLT (M8X1.25X30-MM) | 4 | |
| 9X2099 | 17 STUD (M8X1.25X52.75-MM) | 4 |
