System And Components
326-9156 TURBOCHARGER GPS/N C4Z1-UP
Group No: 326-9156
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0563 | 2 NUT (M10X1.5-THD) | 4 | |
| 1068916 | 3 BOLT (M6X1X16-MM) | 2 | |
| 3617519 | 4 ROD-THREADED | 4 | |
| 1749638 | 5 BOLT (M10X1.5X30-MM) | 8 | |
| 1945390 | 6 GASKET-MANIFOLD | 1 | |
| 3533477 | 7 GASKET-TURBOCHARGER | 1 | |
| 3533478 | 8 GASKET-TURBOCHARGER | 1 | |
| 2258536 | 9 GASKET (MANIFOLD) | 1 | |
| 2373794 | 10 BOLT (M10X1.5-THD) | 1 | |
| 2373921 | 11 CLIP | 1 | |
| 3715700 | 12 MANIFOLD-EXHAUST | 1 | |
| 5075029 | 13 TUBE AS-OIL DRAIN | 1 | |
| 5109628 | 13A CLIP-PIPE | 1 | |
| 2693086 | 13B CLAMP-BAND | 2 | |
| 3229616 | 14 TUBE AS-TURBOCHARGER | 1 | |
| 2258524 | 14A BOLT-SPECIAL (M10X1.5X23-MM) | 2 | |
| 2258526 | 14B WASHER (10.4X13.75X1.37-MM THK) | 4 | |
| 3269153 | 15 TURBOCHARGER | 1 |
