System And Components
341-6719 CONTROL GP-GOVERNORS/N LDY1-281
Group No: 341-6719
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 1514841 | 2 BLOCK | 1 | |
| 1641395 | 3 KNOB (GOVERNOR CONTROL) | 1 | |
| 2061345 | 4 STRAP-CABLE | 1 | |
| 2061692 | 5 COVER AS (CONTROLS, REAR) | 1 | |
| 2061667 | CLIP (TRIM) | 3 | |
| 2093367 | 6 LEVER GP-GOVERNOR (HANDHELD) | 1 | |
| 2093378 | 7 PEDAL GP-GOVERNOR (MECHANICAL) | 1 | |
| 2350128 | 8 CABLE AS | 1 | |
| 5C2890 | NUT (M6X1-THD) | 2 | |
| 8T4742 | END-YOKE ROD | 2 | |
| 8T4744 | PIN AS-SPRING | 2 | |
| 2222690 | CLIP | 1 | |
| 2482707 | 9 GROMMET | 1 | |
| 2507910 | 10 FILM-INSTRUCTION (BOOM LOCK) | 1 | |
| 2507911 | 11 FILM-INSTRUCTION (VARIABLE SPEED) | 1 | |
| 3001702 | 12 BRACKET AS | 1 | |
| 3564070 | 13 PLATE | 1 | |
| 3S2093 | 14 STRAP-CABLE | 2 | |
| 5C2890 | 15 NUT (M6X1-THD) | 2 | |
| 7X0818 | 16 BOLT (M8X1.25X45-MM) | 1 | |
| 8C6802 | 17 SCREW-FLAT HEAD (M6X1X3.72-MM) | 3 | |
| 8T4138 | 18 BOLT (M6X1X20-MM) | 3 | |
| 8T4205 | 19 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4908 | 21 BOLT (M8X1.25X25-MM) | 1 | |
| 9X2038 | 22 WASHER (7X19X2-MM THK) | 4 | |
| 9X2043 | 23 SCREW-TRUSS HEAD (M6X1X14-MM) | 2 |
