System And Components
143-0539 STARTING MOTOR GP-ELECTRICS/N CRS1-UP
Group No: 143-0539
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C9778 | 1 PLUNGER AS | 1 | |
| 8C9783 | 2 GASKET | 1 | |
| 2P8104 | 3 BEARING | 1 | |
| 7T6092 | 4 HOLDER AS-BRUSH | 1 | |
| 8T4133 | 5 NUT (M10X1.5-THD) | 2 | |
| 7T6088 | 6 BEARING AS | 1 | |
| 7T6087 | 7 WASHER (15.2X40X0.5-MM THK) | 1 | |
| 7T6093 | 8 CLUTCH AS | 1 | |
| 8J4455 | 9 BALL | 1 | |
| 7T6090 | 10 SPRING | 1 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 3E5153 | 12 COVER-STARTING MOTOR | 1 | |
| 3E5154 | 13 BUSHING-STARTING MOTOR | 1 | |
| 8F1434 | 14 LOCKWASHER | 1 | |
| 1004113 | 15 SWITCH AS (STARTING MOTOR, 12-VOLT) | 1 | |
| 1004119 | 16 ARMATURE AS | 1 | |
| 1004118 | 17 CASE AS-STARTING MOTOR | 1 | |
| 1004115 | 18 HOUSING-STARTING MOTOR | 1 | |
| 1431344 | 19 FRAME-STARTER | 1 | |
| 1003685 | 20 CAP | 1 | |
| 7T6099 | KIT-GEAR (STARTING MOTOR) | 1 | |
| 8C5457 | KIT-CONTACT (STARTING MOTOR) | 1 | |
| 1466729 | KIT-HARDWARE (STARTING MOTOR) | 1 | |
| 1004112 | KIT-CONTACT (STARTING MOTOR) | 1 |
