System And Components
280-7010 VALVE GP-SOLENOID -TRANSMISSIONS/N LDY1-281
Group No: 280-7010
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3364713 | 1 CARRIER | 2 | |
| 3364714 | 2 SPRING-CENTERING | 2 | |
| 3364722 | 3 POPPET | 2 | |
| 3364728 | 4 BODY-VALVE | 1 | |
| 3364729 | 5 HEAD | 2 | |
| 3366804 | 6 SPACER | 2 | |
| 3366817 | 7 PISTON | 2 | |
| 3366822 | 8 LABEL | 1 | |
| 3366824 | 9 PLUG | 2 | |
| 3366831 | 10 SPRING | 4 | |
| 3366839 | 11 SPOOL | 1 | |
| 3366847 | 12 PLUG | 1 | |
| 8L6565 | 13 PIN-SPRING | 1 | |
| 3366908 | 14 PLUG | 4 | |
| 3366913 | 15 PLUG | 6 | |
| 3366914 | 16 PLUG | 1 | |
| 3367113 | 17 WASHER-SPECIAL | 2 | |
| 3367114 | 18 SPRING | 2 | |
| 3367526 | 19 SEAL-O-RING | 2 | |
| 3367529 | 20 SEAL-O-RING | 2 | |
| 8L2779 | 21 SEAL-O-RING | 4 | |
| 2807009 | 22 COIL AS (12-VOLT) | 2 | |
| 2807012 | 23 SOLENOID AS | 2 | |
| 6V8399 | SEAL-O-RING | 1 | |
| 2744560 | NUT-SELF LOCKING | 1 |
