System And Components
213-1891 FENDER GP-REARS/N LDY1-281
Group No: 213-1891
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1165763 | 1 CLIP-SPRING | 1 | |
| 1939055 | 2 SCREW-HEX FLANGE (M4X1.79X17-MM) | 2 | |
| 2113783 | 3 FENDER-REAR (LH) | 1 | |
| 2131881 | 4 FENDER-REAR (RH) | 1 | |
| 2131884 | 5 CLIP | 1 | |
| 2131889 | 6 PLATE | 1 | |
| 2260291 | 7 LOCK AS (PROTECTION) | 1 | |
| 2275556 | 8 PLATE | 1 | |
| 2475557 | 9 GUARD | 1 | |
| 3762119 | 10 SCREW-BUTTON HEAD | 2 | |
| 1560283 | 11 WASHER-HARD (8.4X35X2.5-MM THK) | 20 | |
| 2131887 | 12 COVER-FENDER | 1 | |
| 5C7261 | 13 NUT (M8X1.25-THD) | 4 | |
| 7Y9099 | 14 SCREW-TRUSS HEAD (M8X1.25X25-MM) | 1 | |
| 8T5093 | 15 BOLT-LOCKING (M8X1.25X25-MM) | 16 | |
| 5P5927 | 16 SEAL (0.8-M) | ||
| 2443113 | 17 SEAL (219-CM EACH) | ||
| 2200738 | 18 SEAL (118-CM) |
