System And Components
341-6677 CONSOLE GP-OPERATOR -RHS/N LDY1-281
Group No: 341-6677
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S3163 | 1 PLUG | 1 | |
| 1641178 | 2 CLIP | 1 | |
| 1678251 | 3 FASTENER | 1 | |
| 2061678 | 4 HOUSING AS (UPPER) | 1 | |
| 2061681 | 5 PANEL AS (LOWER) | 1 | |
| 1728591 | NUT-CLIP (M6X1-THD) | 5 | |
| 2061687 | 6 COVER-FUSE | 1 | |
| 2061690 | 7 COVER (FENDER, REAR) | 1 | |
| 2482709 | 8 PLUG | 2 | |
| 2619644 | 9 COVER AS (CONTROLS, FRONT, LOWER) | 1 | |
| 2061667 | CLIP (TRIM) | 1 | |
| 2619645 | 10 COVER AS (CONTROLS, FRONT, UPPER) | 1 | |
| 2061667 | CLIP (TRIM) | 4 | |
| 2699115 | 11 COVER AS (FENDER, FRONT) | 1 | |
| 1728591 | NUT-CLIP (M6X1-THD) | 1 | |
| 2931980 | 12 SEAL (73-CM) | ||
| 2931980 | 12A SEAL (77.5-CM) | ||
| 3367533 | 13 PANEL AS-GAUGE | 1 | |
| 2061667 | CLIP (TRIM) | 2 | |
| 3375351 | 14 FILM-INSTRUCTION (START SWITCH) | 1 | |
| 9X2038 | 15 WASHER (7X19X2-MM THK) | 5 | |
| 9X2045 | 16 SCREW-TRUSS HEAD (M6X1X20-MM) | 16 |
