System And Components
445-0198 LINES GP-COUPLERS/N LYD1-UP
Group No: 445-0198
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C0754 | 1 TEE | 1 | |
| 7K1181 | 2 STRAP-CABLE | 21 | |
| 1700967 | 3 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5P4906 | ELBOW | 1 | |
| 2794735 | 4 STRAP-CABLE (ORANGE) | 6 | |
| 2794737 | 5 STRAP-CABLE (GREEN) | 6 | |
| 2794738 | 6 STRAP-CABLE (PURPLE) | 6 | |
| 3582091 | 7 VALVE GP-SOLENOID & MANIFOLD (QUICK COUPLER) | 1 | |
| 4415601 | 8 BRACKET | 1 | |
| 4432486 | 9 HOSE AS | 1 | |
| 4463572 | 10 PLATE AS | 1 | |
| 4463575 | 11 BRACKET AS | 2 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 1 | |
| 4463577 | 12 HOSE AS | 3 | |
| 4463580 | 13 HOSE AS | 1 | |
| 4463582 | 14 HOSE AS | 1 | |
| 4480637 | 15 HOSE AS | 3 | |
| 4480652 | 16 BRACKET | 1 | |
| 4480653 | 17 HOSE AS | 1 | |
| 1488307 | 18 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P8874 | ADAPTER | 1 | |
| 1488325 | 19 CONNECTOR AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1488336 | 20 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488433 | 21 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1504052 | 22 UNION AS | 3 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V8993 | UNION | 1 | |
| 2P1279 | 23 LOCKNUT (9/16-18-THD) | 3 | |
| 3597325 | 24 CLAMP-HOSE | 4 | |
| 4J5477 | 25 SEAL-O-RING | 6 | |
| 4P7581 | 26 CLIP (LADDER) | 1 | |
| 5C7261 | 27 NUT (M8X1.25-THD) | 2 | |
| 8R0721 | 28 SPACER (11X16X35-MM THK) | 1 | |
| 8T4121 | 29 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4137 | 30 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4189 | 31 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4197 | 32 BOLT (M8X1.25X40-MM) | 2 | |
| 8T4224 | 33 WASHER-HARD (8.8X16X2-MM THK) | 11 | |
| 8T4908 | 34 BOLT (M8X1.25X25-MM) | 4 | |
| 8T6870 | 35 BOLT (M8X1.25X70-MM) | 1 | |
| 4231984 | 36 HOSE (3.4-IN) | ||
| 4231984 | 36A HOSE (11.5-IN) | ||
| 3622820 | 37 CAP | 4 |
