System And Components
444-1424 SHAFT GP-INPUTS/N HWG1-UP
Group No: 444-1424
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0050469 | 1 CUP-BEARING | 1 | |
| 6V8144 | 2 RING-RETAINING | 2 | |
| 6Y1192 | 3 RING-SEAL | 1 | |
| 9X7684 | 4 SEAL-O-RING | 1 | |
| 0050471 | 5 CONE-BEARING | 1 | |
| 1221886 | 6 RING-SEAL | 3 | |
| 1238905 | 7 CONE-BEARING | 1 | |
| 1238906 | 8 CUP-TAPERED ROLLER | 1 | |
| 3837962 | 9 WASHER-THRUST | 1 | |
| 3837964 | 10 WASHER-THRUST | 1 | |
| 3837974 | 11 GEAR (41-TEETH) | 1 | |
| 3888362 | 12 BEARING-THRUST | 1 | |
| 4259213 | 13 BEARING-NEEDLE | 1 | |
| 4429960 | 14 SPRING-RETURN | 1 | |
| 4429962 | 15 SPRING-RETAINER | 1 | |
| 4433302 | 16 PLATE-CLUTCH | 10 | |
| 4673151 | 17 DISC-FRICTION | 10 | |
| 4437545 | 18 SHAFT AS-INPUT | 1 | |
| 4437549 | 19 GEAR (23-TEETH) | 1 | |
| 4441421 | 20 PISTON | 1 | |
| 4441670 | 21 PLATE-END | 1 | |
| 4475547 | 22 SLEEVE | 1 | |
| 1H8128 | 23 SEAL-O-RING | 1 | |
| 2613255 | 24 RING-RETAINING | 1 |
