Assembly
100%

382-2482 CONTROL GP-SERVICE BRAKES/N HWG1-UP

Group No: 382-2482
Part NumberPart NameQty
7K11811 STRAP-CABLE3
47768962 HOSE1
15148413 BLOCK2
16565954 PIN AS1
17009675 ELBOW AS1
3K0360SEAL-O-RING1
5P4906ELBOW1
45696256 HOSE AS1
20259937 PLATE1
20617668 PIN2
20617679 SPRING (LH)1
220822610 CYLINDER AS (BOOST)1
2624084BOOT2
262408111 END-YOKE ROD2
275065212 PEDAL AS (LH)1
438465412A BUSHING2
275065313 PEDAL AS (RH)1
438465413A BUSHING2
298359914 PLATE AS1
362536415 HOSE AS1
382248616 PLATE AS1
1599539NUT-WELD (M6X1-THD)2
417931917 HOSE AS1
454009718 CLIP2
142048519 NUT (M10X1.5-THD)2
148832520 CONNECTOR AS2
3J1907SEAL-O-RING1
4J5477SEAL-O-RING1
6V8641CONNECTOR1
148837421 ELBOW AS1
3K0360SEAL-O-RING1
6V8397SEAL-O-RING1
6V8723ELBOW1
148837822 ELBOW AS1
3J1907SEAL-O-RING1
6V8397SEAL-O-RING1
6V8724ELBOW1
150303323 ELBOW AS2
3J1907SEAL-O-RING1
4J5477SEAL-O-RING1
8T0164ELBOW1
206176824 SPRING (RH)1
277187325 CLIP (LADDER)1
2K598626 PIN-SPRING1
359732527 CLAMP-HOSE2
5C289028 NUT (M6X1-THD)1
5C726129 NUT (M8X1.25-THD)6
6V735730 BOLT (M6X1X25-MM)1
8T412131 WASHER-HARD (11X21X2.5-MM THK)1
8T413832 BOLT (M6X1X20-MM)1
8T418933 BOLT (M8X1.25X20-MM)4
8T419534 BOLT (M10X1.5X30-MM)1
8T420535 WASHER-HARD (7.2X14.5X2-MM THK)1
8T422436 WASHER-HARD (8.8X16X2-MM THK)10
9R280737 CLIP (RETAINER)2
362282038 CAP2
396054939 SEAL1
9X204540 SCREW-TRUSS HEAD (M6X1X20-MM)4
423198441 HOSE (11.4-IN)
