System And Components
153-8485 CONTROL GP-TRANSMISSIONS/N 5WW1-UP
Group No: 153-8485
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0028588 | 1 YOKE | 1 | |
| 1B8701 | 2 KEY-WOODRUFF | 1 | |
| 1J4384 | 3 PIN-CLEVIS | 3 | |
| 1S1150 | 4 SPACER (0.391X0.5X0.19-IN THK) | 1 | |
| 2L6267 | 5 LOCKNUT (3/8-24-THD) | 7 | |
| 2M8908 | 6 KNOB | 1 | |
| 3T7713 | 7 GASKET | 1 | |
| 3W3110 | 8 LOCK PIN | 3 | |
| 3S6956 | 9 ROD | 1 | |
| 5K7638 | 10 ROD-CONTROL | 1 | |
| 8E5414 | 11 ROD | 1 | |
| 3W3507 | 12 BUSHING | 1 | |
| 3W3598 | 13 LEVER | 1 | |
| 4D4064 | 14 ROD END (3/8-24-THD) | 7 | |
| 4H0407 | 15 PLUG-PROTECTION | 1 | |
| 4H0408 | 16 PLUG-PROTECTION (10-MM) | 3 | |
| 4M8799 | 17 SPRING | 1 | |
| 4Y2804 | 18 SCREW-SOCKET HEAD | 4 | |
| 5B2183 | 19 NUT-JAM (9/16-18-THD) | 1 | |
| 5J5315 | 20 ROD END | 8 | |
| 6Y7901 | 21 LEVER AS | 1 | |
| 6Y7905 | 22 ROD | 1 | |
| 6Y8522 | 23 ROD | 1 | |
| 7M0706 | 24 KNOB | 1 | |
| 7P3006 | 25 LEVER | 4 | |
| 8E5568 | 26 ROD AS | 1 | |
| 8E5571 | 27 BRACKET | 1 | |
| 8E7005 | 28 HARNESS AS | 1 | |
| 8F7702 | 29 SEAL-LIP TYPE | 12 | |
| 8G6017 | 30 SUPPORT | 1 | |
| 8G6711 | 31 LEVER AS | 1 | |
| 4K3893 | BUSHING | 1 | |
| 8G6713 | 32 YOKE AS | 1 | |
| 8G6716 | 33 SUPPORT | 1 | |
| 8G6717 | 34 BELLCRANK | 2 | |
| 8G6718 | 35 SHAFT | 1 | |
| 8G6719 | 36 BRACKET AS | 1 | |
| 8G6723 | 37 COVER AS | 1 | |
| 8G6727 | 38 LEVER AS | 1 | |
| 8G6731 | 39 GUIDE | 1 | |
| 8G6732 | 40 LEVER AS | 1 | |
| 8G6736 | 41 ROD | 1 | |
| 8G6737 | 42 LEVER AS | 1 | |
| 8G6740 | 43 BRACKET AS | 1 | |
| 8G6745 | 44 LEVER AS | 1 | |
| 8G6751 | 45 ADAPTER | 1 | |
| 8G6755 | 46 BRACKET AS | 1 | |
| 8G6769 | 47 LEVER | 1 | |
| 8G8125 | 48 SUPPORT | 1 | |
| 8L8413 | 49 STRAP-CABLE (WHITE) | 1 | |
| 8T1172 | 50 SEAL-LIP TYPE | 2 | |
| 8T1176 | 51 BEARING-ROLLER | 2 | |
| 8T1177 | 52 BEARING-ROLLER | 12 | |
| 8T4838 | 53 BOLT (3/8-16X0.875-IN) | 1 | |
| 8T8614 | 54 RING-LOCK | 1 | |
| 9G0742 | 55 BOOT | 1 | |
| 9G9150 | 56 CLIP | 1 | |
| 9W1581 | 57 SWITCH AS-NEUTRAL START | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 7G1520 | 58 ROD | 1 | |
| 8G6770 | 59 ROD | 1 | |
| 6Y8521 | 60 ROD | 1 | |
| 0343557 | 61 BOLT-LOCKING (3/8-16X1.125-IN) | 1 | |
| 1B8706 | 62 KEY-WOODRUFF | 4 | |
| 1K0485 | 63 WASHER (19.4X34.9X2.5-MM THK) | 10 | |
| 1K6872 | 64 LOCKNUT (1/2-13-THD) | 1 | |
| 1M1341 | 65 END-YOKE ROD | 2 | |
| 2K4973 | 66 LOCKNUT (3/8-16-THD) | 5 | |
| 3B4605 | 67 PIN-COTTER | 1 | |
| 3B4615 | 68 PIN-COTTER | 3 | |
| 3B4617 | 69 PIN-COTTER | 2 | |
| 3H1977 | 70 PIN-CLEVIS | 1 | |
| 4K5175 | 71 BOLT-12 POINT HEAD (1/2-13X1.5-IN) | 1 | |
| 4L6454 | 72 BOLT (3/8-16X1-IN) | 30 | |
| 4M7680 | 73 PIN | 1 | |
| 5H9899 | 74 RING-RETAINING (EXTERNAL) | 1 | |
| 5S7379 | 75 BOLT (3/8-16X0.875-IN) | 2 | |
| 5S7382 | 76 BOLT (3/8-16X1.375-IN) | 6 | |
| 5S7383 | 77 BOLT (3/8-16X1.75-IN) | 4 | |
| 6V8183 | 78 NUT-FULL (3/8-24-THD) | 11 | |
| 6V8185 | 79 NUT (1/4-20-THD) | 1 | |
| 6V8801 | 80 NUT (3/8-16-THD) | 4 | |
| 8T4205 | 81 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T4223 | 82 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4896 | 83 WASHER-HARD (10.2X18.5X2.5-MM THK) | 32 | |
| 8T8919 | 84 BOLT (1/2-13X1.75-IN) | 1 | |
| 8T9364 | 85 BOLT (1/4-20X0.625-IN) | 3 | |
| 3S2713 | 86 NUT-FULL (3/8-24-THD) | 8 |
