System And Components
256-4802 AIR COMPRESSOR GPS/N C9S1-1743
Group No: 256-4802
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1359819 | 1 SEAL-INTEGRAL | 1 | |
| 2201715 | 2 HOSE AS | 1 | |
| 2418046 | 3 BRACKET AS | 1 | |
| 2467095 | 4 AIR COMPRESSOR GP | 1 | |
| 0307942 | 5 ELBOW | 1 | |
| 0307946 | 6 ELBOW | 1 | |
| 1833406 | 7 PLUG AS | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 2255222 | 8 VALVE AS-PRESSURE RELIEF (AIR COMPRESSOR) | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 2P8421 | 10 ADAPTER-O-RING | 1 | |
| 3D2824 | 11 SEAL-O-RING | 1 | |
| 3J1907 | 12 SEAL-O-RING | 1 | |
| 3J7354 | 13 SEAL-O-RING | 1 | |
| 5P8245 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V3822 | 15 BOLT (M10X1.5X35-MM) | 2 | |
| 6V5049 | 16 SEAL-O-RING | 1 | |
| 6V8336 | 18 BOLT (M12X1.75X70-MM) | 2 | |
| 8C8585 | 19 SCREW-BUTTON HEAD (M10X1.5X20-MM) | 2 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 9S8004 | 22 PLUG (9/16-18-THD) | 1 |
