System And Components
282-0551 AIR COMPRESSOR GPS/N C9S228-UP
Group No: 282-0551
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2820544 | 1 AIR COMPRESSOR GP | 1 | |
| 0907055 | 2 HOSE AS | 1 | |
| 2936620 | 3 BRACKET AS | 1 | |
| 0307946 | 4 ELBOW | 1 | |
| 5P8245 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V4248 | 6 BOLT (M10X1.5X25-MM) | 1 | |
| 6V5048 | 7 SEAL-O-RING | 1 | |
| 6V5839 | 8 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V8260 | 9 SEAL-O-RING | 1 | |
| 6V8336 | 10 BOLT (M12X1.75X70-MM) | 2 | |
| 6D3479 | 11 CLIP (LOOP) | 1 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 2 | |
| 9X2040 | 14 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 2 | |
| 2255222 | 15 VALVE AS-PRESSURE RELIEF (AIR COMPRESSOR) | 1 | |
| 2M9780 | 15A SEAL-O-RING | 1 |
