System And Components
290-1234 GEAR GP-REAR -PTOS/N C9S1-UP
Group No: 290-1234
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1T0808 | 1 WASHER (0.516X0.812X0.09-IN THK) | 1 | |
| 4P3325 | 2 PLATE-THRUST | 1 | |
| 4P3647 | 3 GEAR AS (43-TEETH) | 1 | |
| 9M2418 | BUSHING | 1 | |
| 4P4178 | 4 WASHER-THRUST | 1 | |
| 4P4181 | 5 WASHER-THRUST | 1 | |
| 7C1445 | 6 COVER | 1 | |
| 1075806 | 7 GEAR (46-TEETH) | 1 | |
| 1075807 | 8 GEAR (35-TEETH) | 1 | |
| 1095290 | 9 CARRIER AS-BEARING | 1 | |
| 5S8543 | BUSHING | 1 | |
| 1095292 | 10 SHAFT-IDLER GEAR | 1 | |
| 1105145 | 11 SHAFT-OUTPUT | 1 | |
| 1570058 | 12 COVER AS | 1 | |
| 3F6795 | DOWEL | 2 | |
| 1602283 | 13 GASKET | 1 | |
| 2151825 | 14 GASKET | 1 | |
| 2857621 | 15 HOUSING GP-FLYWHEEL | 1 | |
| 0619455 | 16 SEAL-O-RING | 1 | |
| 3E6768 | 17 SEAL-LIP TYPE | 1 | |
| 5P7701 | 18 SEAL-O-RING | 1 | |
| 5P8245 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 13 | |
| 6V1197 | 20 SEAL-O-RING | 1 | |
| 6V5048 | 21 SEAL-O-RING | 1 | |
| 6V5049 | 22 SEAL-O-RING | 2 | |
| 6V5134 | 23 SEAL-O-RING | 1 | |
| 6V5230 | 24 BOLT (M10X1.5X60-MM) | 2 | |
| 6V5839 | 25 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V8214 | 26 BOLT (M6X1X20-MM) | 3 | |
| 6V8490 | 27 BOLT (M6X1X25-MM) | 4 | |
| 6V8837 | 28 BOLT (M6X1X16-MM) | 2 | |
| 7X0870 | 29 BOLT (M8X1.25X140-MM) | 2 | |
| 8L2786 | 30 SEAL-O-RING | 2 | |
| 8T0273 | 31 BOLT-SOCKET HEAD (M12X1.75X40-MM) | 12 | |
| 8T3957 | 32 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 8 | |
| 8T7811 | 33 BOLT-SOCKET HEAD (M12X1.75X50-MM) | 2 | |
| 9M1974 | 34 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S4182 | 35 PLUG (7/16-20-THD) | 1 | |
| 9S4185 | 36 PLUG (3/4-16-THD) | 2 | |
| 9S8004 | 37 PLUG (9/16-18-THD) | 2 | |
| 9S9334 | 38 PLUG (1-5/16-12-THD) | 1 | |
| 9X4576 | 39 SEAL-O-RING | 1 | |
| 9X7287 | 40 SEAL-O-RING | 1 | |
| 9X8267 | 41 WASHER (6.6X12X2-MM THK) | 7 |
