System And Components
255-6267 LINES GP-AIR COMPRESSORS/N C9S1-UP
Group No: 255-6267
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2578751 | 1 VALVE AS (AIR COMPRESSOR LINE) | 1 | |
| 6V7728 | 1A BOLT (M6X1X45-MM) | 4 | |
| 1785544 | 1B SPACER (6.6X13X18-MM THK) | 4 | |
| 2454393 | 1C GASKET | 1 | |
| 2396896 | 2 TUBE AS | 1 | |
| 2409982 | 3 BRACKET | 1 | |
| 0308190 | 4 CONNECTOR | 1 | |
| 2R6276 | 5 CONNECTOR | 1 | |
| 6V1903 | 7 SEAL-O-RING | 1 | |
| 6V3940 | 8 BOLT (M8X1.25X25-MM) | 2 | |
| 6V5050 | 9 SEAL-O-RING | 2 | |
| 6V5224 | 10 BOLT (M16X2X25-MM) | 2 | |
| 8K2377 | 11 ELBOW-FLARED | 1 | |
| 9M1974 | 12 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X8268 | 13 WASHER (17.5X30X3.5-MM THK) | 2 |
