164-6916 VALVE GP-CONTROL -IMPLEMENT, TRAVELS/N AAT1-UP

Group No: 164-6916
Part NumberPart NameQty
6J72401 SPRING3
9T98272 COVER1
9S41913 PLUG (9/16-18-THD)17
3J19074 SEAL-O-RING22
9S41805 PLUG31
4J75336 SEAL-O-RING31
9S41837 PLUG (1-1/16-12-THD)2
3D28248 SEAL-O-RING4
6V55559 SEAL-O-RING2
1H572810 SEAL-O-RING9
129031811 NUT (7/16-14-THD)6
129031912 SCREW-ADJUSTMENT (7/16-14-THD)6
6E583013 RETAINER-SPRING6
172674114 SPRING2
147122315 VALVE GP-SOLENOID (24-VOLT)(24 VOLTS)(NEUTRAL BYPASS)1
9S801016 PLUG1
2S407817 SEAL-O-RING1
5J500418 PLUG-ORIFICE5
1P370619 SEAL-RECTANGULAR3
9F216720 SCREW-PURGE (3/8-24X1.164-IN)6
160743921 VALVE GP-MAKEUP (RH TRAVEL)2
100621122 PISTON3
1J967123 SEAL-O-RING3
3K846024 PLUG (1/2-20-THD)3
119461825 RETAINER1
119461326 RETAINER2
194616027 MANIFOLD1
7X255528 BOLT (M16X2X80-MM)8
206748529 VALVE GP-RELIEF (WORK TOOL LINE & MAKEUP)2
224388830 MANIFOLD1
7X254531 BOLT (M10X1.5X150-MM)8
7X254732 BOLT (M10X1.5X200-MM)8
119612933 RETAINER2
224389234 SPACER (12.7X6.2X1.95-MM THK)1
3J735435 SEAL-O-RING4
4T186036 VALVE GP-SHUTTLE (BALL RESOLVER)1
6E442937 VALVE GP-SHUTTLE (BALL RESOLVER)1
3F884540 SPRING1
1B790441 SPACER (6.8X10X9.5-MM THK)3
119613042 RETAINER1
9T964044 VALVE GP-SHUTTLE (BALL RESOLVER)5
9S800446 PLUG (9/16-18-THD)5
9M066947 DOWEL2
224388648 MANIFOLD1
3D460349 PLUG-PIPE2
6J313450 SEAL-O-RING15
6V974651 SEAL-O-RING6
9S800853 PLUG (1-1/16-12-THD)2
9S800256 PLUG (7/16-20-THD)2
9S418557 PLUG (3/4-16-THD)6
3K036058 SEAL-O-RING6
9T830959 SPRING4
9T908361 VALVE GP-RELIEF (MAIN)1
1W652362 PLUG2
160743963 VALVE GP-MAKEUP (LH TRAVEL)2
