Assembly
100%

7N-1493 RADIATOR GPS/N 9HJ1-816

Group No: 7N-1493
Part NumberPart NameQty
1P72751 BAFFLE AS-RADIATOR1
5S73792 BOLT (3/8-16X0.875-IN)18
8T48963 WASHER-HARD (10.2X18.5X2.5-MM THK)14
6L86174 CAP-PRESSURE (7-PSI)1
8N49735 RADIATOR AS1
9B72376 BOLT (3/8-16X1.25-IN)8
5P10757 WASHER-HARD (10.2X22.5X3-MM THK)16
5P12598 HOSE (17.8CM 7IN)2
6N87449 MOUNT8
7X0578WASHER-HARD (10.2X32X2.5-MM THK)16
1P714510 SHIELD AS-FAN1
1P727711 BAFFLE AS-RADIATOR1
1P731112 BAFFLE2
1P729613 STRIP4
5P076714 HOSE (38.1M 15IN)
003214315 ELBOW1
8F8151VALVE-SHUTOFF1
1P714316 SHIELD AS-FAN1
5P486817 CLAMP-HOSE2
2P744318 HOSE-RADIATOR1
5P059719 CLAMP-HOSE2
1P729920 BAFFLE2
8T250221 BOLT (3/8-16X1.125-IN)4
