System And Components
2T-3399 SUSPENSION GP-FRONTS/N 9XG1413-1700
Group No: 2T-3399 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1879105 | 1 VALVE GP-LEVELING (CUSHION HITCH) | 1 | |
| 5P9085 | 2 CLIP (LOOP) | 1 | |
| 6E3450 | 3 ACCUMULATOR GP-HYDRAULIC (CUSHION-HITCH) | 1 | |
| 3G7274 | 4 CYLINDER GP-LOAD (CUSHION-HITCH) | 2 | |
| 1024227 | 5 PUMP GP-PISTON | 1 | |
| 2T0322 | 7 ARM AS-LEADING | 1 | |
| 2T0334 | 8 LINK-LEADING ARM | 1 | |
| 2T0318 | 9 PLATE (RH) | 1 | |
| 2T0317 | 10 BRACKET AS | 1 | |
| 2T0319 | 11 PLATE (LH) | 1 | |
| 2T0316 | 12 BRACKET AS | 1 | |
| 2T0324 | 13 ARM AS-TRACK | 1 | |
| 2T2590 | 14 BRACKET AS | 1 | |
| 5B5840 | SPACER (0.563X1X0.563-IN THK) | 2 | |
| 6M4016 | LUG | 2 | |
| 8I2382 | 15 BRACKET AS | 1 | |
| 2T0785 | 16 ROD | 1 | |
| 0666566 | 17 YOKE-ADJUSTMENT | 1 | |
| 9B1041 | 18 PIN | 1 | |
| 3B4615 | 19 PIN-COTTER | 3 | |
| 6G5003 | 20 BLOCK-PIVOT | 1 | |
| 4K1540 | 21 PIN-CLEVIS | 1 | |
| 8J1081 | 22 SPRING-LEAF | 1 | |
| 8T4896 | 23 WASHER-HARD (10.2X18.5X2.5-MM THK) | 32 | |
| 3B6552 | 24 ELBOW-PIPE | 2 | |
| 4D4064 | 25 ROD END (3/8-24-THD) | 1 | |
| 7X0320 | 26 BOLT (7/16-14X5-IN) | 3 | |
| 7K1181 | 27 STRAP-CABLE | 10 | |
| 6B1329 | 28 PAD-SHIFT BASE | 1 | |
| 2T2927 | 29 HOSE AS | 2 | |
| 3S8665 | 30 CLIP (LOOP) | 1 | |
| 2T0312 | 31 PIN AS | 2 | |
| 7X0447 | 32 NUT (7/16-14-THD) | 3 | |
| 8T4835 | 33 BOLT (1/2-13X2-IN) | 16 | |
| 6V8188 | 34 NUT (1/2-13-THD) | 6 | |
| 8T4122 | 35 WASHER-HARD (17X32X3.5-MM THK) | 3 | |
| 2T2924 | 36 HOSE AS | 2 | |
| 7X0325 | 37 BOLT (1/2-13X2.5-IN) | 4 | |
| 5P2566 | 38 BOLT (1/2-13X1.5-IN) | 12 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 52 | |
| 8J4741 | 40 BAR | 8 | |
| 7X0414 | 41 BOLT (1-8X7.5-IN) | 4 | |
| 5P8444 | 42 GROMMET (37-MM ID) | 1 | |
| 7J9385 | 43 WASHER-THRUST | 4 | |
| 5T1246 | 44 BEARING | 4 | |
| 2T3252 | 45 RETAINER-PLATE | 4 | |
| 5P7469 | 46 CLIP (TAB) | 1 | |
| 7J6869 | 47 RING | 8 | |
| 8T1889 | 48 CLIP (SLOT) | 4 | |
| 2T0835 | 49 ANGLE AS | 1 | |
| 8T8917 | 50 BOLT (1/2-13X1.25-IN) | 18 | |
| 2T0310 | 51 PIN AS (3.5-MM THK) | 2 | |
| 2T3505 | 52 PIN | 2 | |
| 2T0332 | 53 RING | 4 | |
| 7K4364 | 54 BOLT (1-8X15.25-IN) | 8 | |
| 6V8190 | 55 NUT (1-8-THD) | 12 | |
| 8T5361 | 56 WASHER-HARD (28X49X5-MM THK) | 12 | |
| 7X0384 | 57 BOLT (7/8-9X3-IN) | 4 | |
| 2T0313 | 58 LUG AS | 1 | |
| 1K6985 | 59 RING-RETAINING | 4 | |
| 7J5279 | 60 WASHER-SPECIAL | 4 | |
| 6V5002 | 61 BEARING-ALIGNING | 2 | |
| 2T0309 | 62 PIN AS | 2 | |
| 2T0333 | 63 RING | 4 | |
| 5P8167 | 64 BOLT (3/8-16X0.625-IN) | 1 | |
| 2T2581 | 65 HOSE AS | 1 | |
| 7X0444 | 66 BOLT (1-8X6.5-IN) | 4 | |
| 8I1867 | 67 BRACKET AS | 1 | |
| 8I1951 | 68 CLIP | 1 | |
| 5P7468 | 71 CLIP (SLOT) | 1 | |
| 6V5003 | 72 BEARING | 2 | |
| 1J6472 | 73 RING-RETAINING | 4 | |
| 6V8397 | 74 SEAL-O-RING | 1 | |
| 4J0520 | 75 SEAL-O-RING | 2 | |
| 1488381 | 77 ELBOW AS | 1 | |
| 8T5429 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 4L6454 | 78 BOLT (3/8-16X1-IN) | 10 | |
| 3S8664 | 79 CLIP | 2 | |
| 2T3772 | 80 TUBE AS | 1 | |
| 2T2937 | 81 HOSE AS | 1 | |
| 8J8197 | 82 CLIP | 3 | |
| 8C6913 | 83 WASHER-HARD (24X41.5X4-MM THK) | 4 | |
| 1654927 | 84 CONNECTOR AS | 1 | |
| 2T2991 | CONNECTOR | 1 | |
| 4K1388 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488367 | 85 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488378 | 86 ELBOW AS | 2 | |
| 6V8724 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9746 | 87 SEAL-O-RING | 8 | |
| 2T0914 | 88 ADAPTER | 1 | |
| 5M3062 | 89 BOLT (3/8-16X0.75-IN) | 14 | |
| 2T0311 | 90 PIN | 2 | |
| 5B1983 | 91 BOSS (3/8-16-THD) | 2 | |
| 1488318 | 93 CONNECTOR AS | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1887 | 94 CLIP (SLOT) | 8 | |
| 9F4233 | 95 BUSHING-TERMINAL | 1 | |
| 6B6683 | 97 NUT (5/8-18-THD) | 1 | |
| 1P4578 | 98 FLANGE-HALF | 10 | |
| 4J0522 | 99 SEAL-O-RING | 7 | |
| 8T8916 | 100 BOLT (7/16-14X1.5-IN) | 20 | |
| 8T5360 | 101 WASHER (12X22.5X2.5-MM THK) | 26 | |
| 2T2573 | 102 TUBE AS | 1 | |
| 2T2574 | 103 TUBE AS | 1 | |
| 8I1992 | 104 TUBE AS | 1 | |
| 2T0885 | 105 BLOCK | 2 | |
| 2T2583 | 106 HOSE AS | 2 | |
| 4D6475 | 107 ELBOW | 10 | |
| 2T2577 | 108 TUBE AS | 1 | |
| 8I1080 | 109 HOSE AS | 1 | |
| 4H1477 | 110 PIN | 1 | |
| 5K9090 | 111 SEAL-O-RING | 1 | |
| 2T2923 | 112 HOSE AS | 1 | |
| 6V8801 | 113 NUT (3/8-16-THD) | 2 | |
| 2T2579 | 114 TUBE AS | 1 | |
| 2T2582 | 115 HOSE AS | 2 | |
| 2T2580 | 116 TUBE AS | 1 | |
| 8T1888 | 117 CLIP (TAB) | 8 | |
| 2T3019 | 118 CLIP (LOOP) | 3 | |
| 8T9377 | 119 BOLT (3/8-16X2.25-IN) | 2 | |
| 2T1051 | 120 HOSE AS | 1 | |
| 2T0850 | 121 HEAD | 2 | |
| 8I1579 | 122 GEAR-HYDRAULIC PUMP DRIVE (33-TEETH) | 1 | |
| 2T2614 | 123 HOSE AS | 1 | |
| 5T9813 | 124 HOSE AS | 1 | |
| 2T2613 | 125 HOSE AS | 1 | |
| 2T3011 | 126 HOSE AS | 1 | |
| 2T1050 | 127 HOSE AS | 1 | |
| 2H6338 | 129 SEAL-O-RING | 1 | |
| 8T1890 | 130 CLIP (TAB) | 4 | |
| 4D7794 | 131 CLIP | 5 | |
| 2T1049 | 132 HOSE AS | 1 | |
| 2T1052 | 133 HOSE AS | 1 | |
| 1488444 | 134 TEE AS-SWIVEL | 1 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8398 | 135 SEAL-O-RING | 1 | |
| 8T2502 | 136 BOLT (3/8-16X1.125-IN) | 2 | |
| 3P2404 | 137 CLIP | 1 | |
| 3S2713 | 138 NUT-FULL (3/8-24-THD) | 2 | |
| 5K5338 | 139 CLIP (LOOP)(DOUBLE) | 1 | |
| 3B8489 | 140 FITTING-GREASE (1/8-27 PTF)(CENTRAL LUBRICATION) | 12 | |
| 1488358 | 141 ELBOW AS | 1 | |
| 6V8624 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1620177 | 142 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1488330 | 144 CONNECTOR AS | 1 | |
| 8T0198 | CONNECTOR | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 7I4602 | 146 STRIP-RUBBER | 1 | |
| 8T4121 | 147 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4196 | 148 BOLT (M10X1.5X35-MM) | 3 | |
| 2T2942 | 149 HOSE AS | 1 | |
| 2T2926 | 150 HOSE AS | 1 | |
| 8W3174 | 151 PLATE AS | 1 | |
| 7D2746 | 152 ELBOW | 2 | |
| 9B7237 | 153 BOLT (3/8-16X1.25-IN) | 1 | |
| 5F3106 | 154 SEAL-O-RING | 1 | |
| 8T9393 | 155 BOLT (5/8-11X1.5-IN) | 2 |
