System And Components
6Y-4743 LINES GP-STEERINGS/N 7TK396-99999
Group No: 6Y-4743
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4896 | 1 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 3J1907 | 2 SEAL-O-RING | 21 | |
| 5P2566 | 3 BOLT (1/2-13X1.5-IN) | 6 | |
| 8T4223 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 21 | |
| 7G3833 | 5 CLIP (TAB) | 4 | |
| 7G3834 | 6 CLIP (SLOT) | 4 | |
| 7G3832 | 7 GROMMET | 4 | |
| 6Y5433 | 8 BLOCK | 2 | |
| 6Y5432 | 9 PLATE | 1 | |
| 4L6454 | 10 BOLT (3/8-16X1-IN) | 1 | |
| 5P1075 | 11 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 6V8716 | 12 CONNECTOR (STRAIGHT) | 5 | |
| 7M8485 | 13 SEAL-O-RING | 10 | |
| 6Y4053 | 14 HOSE AS | 1 | |
| 6V9746 | 15 SEAL-O-RING | 24 | |
| 6Y8199 | 16 HOSE AS | 1 | |
| 1P5766 | 17 FLANGE-HALF | 4 | |
| 8T5360 | 18 WASHER (12X22.5X2.5-MM THK) | 12 | |
| 7X0332 | 19 BOLT (1/2-13X4.5-IN) | 3 | |
| 1P5767 | 20 FLANGE-HALF | 4 | |
| 8C6877 | 21 BOLT (7/16-14X1.75-IN) | 8 | |
| 6V9182 | 22 ELBOW | 1 | |
| 1536236 | 23 REDUCER AS | 1 | |
| 5K9090 | 24 SEAL-O-RING | 5 | |
| 6V9008 | 25 ELBOW (90-DEG) | 1 | |
| 6Y4061 | 26 HOSE AS | 1 | |
| 6Y4058 | 27 HOSE AS | 1 | |
| 1P3703 | 28 SEAL-RECTANGULAR | 2 | |
| 1P3704 | 29 SEAL-RECTANGULAR | 2 | |
| 5S7383 | 30 BOLT (3/8-16X1.75-IN) | 1 | |
| 6V8629 | 31 ELBOW | 1 | |
| 2M9780 | 32 SEAL-O-RING | 4 | |
| 6V8640 | 33 CONNECTOR | 2 | |
| 6Y4055 | 34 HOSE AS | 1 | |
| 6V9005 | 35 ELBOW | 1 | |
| 6Y4048 | 36 HOSE AS | 1 | |
| 3D2824 | 37 SEAL-O-RING | 2 | |
| 6V9007 | 38 ELBOW | 1 | |
| 6Y4052 | 39 HOSE AS | 1 | |
| 6Y4047 | 40 HOSE AS | 1 | |
| 3K0360 | 41 SEAL-O-RING | 2 | |
| 6V1722 | 42 ADAPTER | 1 | |
| 6V8634 | 43 CONNECTOR | 2 | |
| 9W7649 | 44 BRACKET | 1 | |
| 6Y0594 | 45 HOSE AS | 1 | |
| 9B7237 | 46 BOLT (3/8-16X1.25-IN) | 2 | |
| 5P7462 | 47 CLIP (SLOT) | 3 | |
| 5P7463 | 48 CLIP (TAB) | 3 | |
| 6V8801 | 49 NUT (3/8-16-THD) | 1 | |
| 6V8781 | 50 TEE | 1 | |
| 6Y4050 | 51 HOSE AS | 1 | |
| 6V8397 | 52 SEAL-O-RING | 35 | |
| 8T4149 | 53 ELBOW | 1 | |
| 6V8635 | 54 CONNECTOR | 1 | |
| 8T1120 | 55 TEE-O-RING PORT | 1 | |
| 2S4078 | 56 SEAL-O-RING | 1 | |
| 6K6307 | 57 SEAL-O-RING | 1 | |
| 6Y4062 | 58 HOSE AS | 1 | |
| 5C6565 | 59 BOLT (1/2-13X1.125-IN) | 2 | |
| 6Y4046 | 60 HOSE AS | 2 | |
| 6Y5440 | 61 HOSE AS | 1 | |
| 0321853 | 62 BOLT-12 POINT HEAD (3/4-10X2-IN) | 2 | |
| 2S0115 | 63 WASHER-HARD (20X36.5X5-MM THK) | 2 | |
| 2K8257 | 64 SEAL-O-RING | 1 | |
| 6V8636 | 65 CONNECTOR | 2 | |
| 8T1905 | 66 ELBOW | 1 | |
| 1P4578 | 67 FLANGE-HALF | 2 | |
| 8T8916 | 68 BOLT (7/16-14X1.5-IN) | 4 | |
| 6V8724 | 69 ELBOW | 2 | |
| 6Y4045 | 70 HOSE AS | 2 | |
| 8E2370 | 71 HOSE AS | 2 | |
| 6V8994 | 72 UNION (STRAIGHT) | 2 | |
| 6V9168 | 73 NUT (11/16-16-THD) | 4 | |
| 7X0820 | 74 TEE | 2 | |
| 6V9829 | 75 CAP (ORFS) | 2 | |
| 5P2424 | 76 BOLT (1/2-13X2.25-IN) | 1 | |
| 6V8188 | 77 NUT (1/2-13-THD) | 1 | |
| 6Y4054 | 78 HOSE AS | 1 | |
| 8T5389 | 79 ELBOW | 1 | |
| 7X0772 | 80 WASHER-HARD (10.2X25.5X2.5-MM THK) | 3 | |
| 0920759 | 81 HOSE AS | 1 | |
| 7X2459 | 82 ADAPTER-TEE | 2 | |
| 6V3965 | 83 FITTING (QUICK DISCONNECT) | 7 | |
| 6V0852 | 84 CAP-DUST | 7 | |
| 5P7459 | 85 CLIP (TAB) | 1 | |
| 8C3323 | 86 CONNECTOR | 1 | |
| 6V0683 | 87 GROMMET | 2 | |
| 6V0484 | 88 ELBOW | 4 | |
| 5S7379 | 89 BOLT (3/8-16X0.875-IN) | 1 | |
| 5P7458 | 90 CLIP (SLOT) | 1 | |
| 8T4835 | 91 BOLT (1/2-13X2-IN) | 8 | |
| 8C4985 | 92 ADAPTER | 1 |
