System And Components
9C-8172 BRAKE & PLANETARY GPS/N 6WS1-UP
Group No: 9C-8172
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4E2168 | 1 PISTON | 1 | |
| 6Y2082 | 2 DISC-FRICTION | 1 | |
| 9M4335 | 3 DOWEL-REACTION | 3 | |
| 4E2167 | 4 SPRING | 3 | |
| 9C6329 | 5 PLATE-REACTION | 1 | |
| 4E2165 | 6 GEAR-SUN (18-TEETH)(18 TEETH) | 1 | |
| 4E2166 | 7 CARRIER-PLANETARY | 1 | |
| 9C6335 | 8 GEAR-PLANETARY (29-TEETH)(29 TEETH) | 3 | |
| 9C6317 | 9 SHAFT-PLANETARY | 3 | |
| 9C6318 | 10 BUSHING | 3 | |
| 9C6342 | 11 WASHER-THRUST | 6 | |
| 8T2925 | 12 PIN-SPRING | 3 | |
| 8R1891 | 13 GEAR-RING (78-TEETH)(78 TEETH) | 1 | |
| 1155327 | 14 DOWEL | 3 | |
| 1463642 | 15 SEAL AS | 1 | |
| 4E0211 | 16 SEAL | 1 | |
| 1381645 | 17 PIN-SPRING | 3 |
