System And Components
100-3811 HOUSING GP-FIXED AXLES/N 2RM1-1409
Group No: 100-3811
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9W6671 | 1 SEAL GP-DUO-CONE | 2 | |
| 5P8247 | 2 WASHER-HARD (17X32X3.5-MM THK) | 52 | |
| 8T0649 | 3 BOLT (M16X2X110-MM) | 22 | |
| 1U8846 | 4 SEALANT-GASKET | ||
| 5H3701 | 5 SCREW-PURGE | 2 | |
| 8T0336 | 6 FITTING-PRESSURE RELIEF | 1 | |
| 8T5002 | 7 BOLT (M16X2X180-MM) | 22 | |
| 7X2465 | 8 BOLT (M24X3X180-MM) | 8 | |
| 8T4167 | 9 WASHER-HARD (26X44X4-MM THK) | 8 | |
| 6Y1032 | 10 CUP-BEARING | 2 | |
| 6Y1031 | 11 CONE-BEARING | 2 | |
| 9C6312 | 12 SHAFT-AXLE | 2 | |
| 8T4224 | 13 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T5093 | 14 BOLT-LOCKING (M8X1.25X25-MM) | 6 | |
| 8T0375 | 15 BOLT (M16X2X45-MM) | 8 | |
| 6F4718 | 16 SEAL-O-RING | 1 | |
| 4E3999 | 17 SHIM PACK (INCLUDES 10-SHIMS) | 1 | |
| 4E3997 | 18 HOUSING-PINION | 1 | |
| 4E4142 | 19 RETAINER-SEAL | 1 | |
| 4E4003 | 20 HOUSING AS | 1 | |
| 5P4484 | 21 PLUG-MAGNETIC | 1 | |
| 7M8485 | 22 SEAL-O-RING | 3 | |
| 9S4181 | 23 PLUG (1-5/16-12-THD) | 2 | |
| 2K9295 | 24 BEARING AS-TAPERED ROLLER | 2 | |
| 3B4124 | 25 CUP-BEARING (TAPERED ROLLER) | 2 | |
| 9C6313 | 26 NUT-BEARING | 2 | |
| 8T3727 | 27 RING-RETAINING | 2 | |
| 9C6041 | 28 DOWEL | 3 | |
| 6V7196 | 29 SEAL-LIP TYPE | 1 | |
| 3B0551 | 30 PLUG-PIPE | 1 | |
| 8R0512 | 31 GAUGE AS-OIL LEVEL (DIPSTICK) | 1 | |
| 1155826 | 32 HOUSING-AXLE SHAFT | 2 |
