System And Components
111-8787 TURBOCHARGER GPS/N 5HK24000-99999
Group No: 111-8787
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S3440 | 1 CLAMP-HOSE | 2 | |
| 5C4647 | 2 SPACER | 1 | |
| 1004453 | 3 STUD | 6 | |
| 6I0217 | 4 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0220 | 5 GASKET | 1 | |
| 6I0563 | 6 NUT (M10X1.5-THD) | 7 | |
| 6I0572 | 7 BOLT (M8X1.25X20-MM) | 2 | |
| 1004466 | 8 GASKET | 1 | |
| 6I1132 | 9 GASKET | 1 | |
| 6I4012 | 10 STUD | 7 | |
| 6I4196 | 11 TUBE | 1 | |
| 1407560 | 12 HOSE | 1 | |
| 6I4198 | 13 TUBE | 1 | |
| 6I4199 | 14 TUBE AS | 1 | |
| 5D6523 | 15 CLIP | 1 | |
| 1188384 | 16 TURBOCHARGER GP | 1 | |
| 0328048 | 17 FERRULE | 1 | |
| 4P1665 | 18 SLEEVE-OUTLET | 1 | |
| 6I4013 | 19 FLANGE | 1 | |
| 7W2581 | 20 GASKET | 1 | |
| 7W2628 | 21 NUT | 1 | |
| 7W2634 | 22 UNION | 1 | |
| 1061317 | 23 ELBOW-EXHAUST | 1 | |
| 6I4039 | 24 GASKET | 1 | |
| 6I0260 | 25 BOLT (M8X1.25X25-MM) | 2 | |
| 1004454 | 26 NUT | 6 | |
| 1004467 | 27 BRACKET | 1 | |
| 6I3812 | 28 BOLT (M8X1.25X16-MM) | 5 | |
| 1004830 | 29 BOLT (M10X1.5X20-MM) | 2 | |
| 6I4200 | 30 BOLT (M10X1.5X16-MM) | 1 |
