System And Components
209-6821 AIR COMPRESSOR GPS/N 7BJ25913-UP
Group No: 209-6821
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D1026 | 1 CLAMP-BAND | 4 | |
| 6I0233 | 2 NUT (M12X1.75-THD) | 3 | |
| 6I0260 | 3 BOLT (M8X1.25X25-MM) | 2 | |
| 6I4200 | 4 BOLT (M10X1.5X16-MM) | 2 | |
| 0358017 | 5 UNION | 1 | |
| 6I0217 | 6 BOLT (M8X1.25X20-MM) | 1 | |
| 0676810 | 7 WASHER | 1 | |
| 1004830 | 8 BOLT (M10X1.5X20-MM) | 1 | |
| 1013917 | 9 WASHER (10.5X21X2-MM THK) | 2 | |
| 1134608 | 10 ADAPTER | 1 | |
| 1134616 | 11 CONNECTOR | 2 | |
| 1243815 | 12 BOLT (M8X1.25X16-MM) | 3 | |
| 1263204 | 13 GEAR (28-TEETH) | 1 | |
| 1263205 | 14 BRACKET | 1 | |
| 1263206 | 15 HUB | 1 | |
| 1263207 | 16 SEAL-O-RING | 1 | |
| 1263208 | 17 BEARING | 1 | |
| 1263209 | 18 GEAR (32-TEETH) | 1 | |
| 1263210 | 19 PLATE | 1 | |
| 1263211 | 20 BOLT | 3 | |
| 1263212 | 21 BOLT (M8X1.25X25-MM) | 4 | |
| 1263216 | 22 STUD | 1 | |
| 1263217 | 23 STUD | 1 | |
| 1263219 | 24 SEAL-O-RING | 1 | |
| 2096816 | 25 AIR COMPRESSOR GP | 1 | |
| 2096817 | 26 PLATE AS | 1 | |
| 2101074 | 27 SEAL-O-RING | 1 | |
| 2096824 | 28 HOSE | 1 | |
| 2096825 | 29 ADAPTER | 2 | |
| 2096833 | 30 HOSE | 1 | |
| 2096834 | 31 BRACKET | 1 | |
| 2101077 | 32 PIPE AS | 1 | |
| 1278281 | 35 CLIP | 1 | |
| 2474928 | 36 WASHER (16.5X20.5X1.6-MM THK) | 2 | |
| 2101508 | WASHER | 2 | |
| 2096881 | KIT-SEAL (COMPRESSOR)(AIR) | 1 | |
| 2096882 | KIT-REPAIR (AIR COMPRESSOR PISTON) | 1 | |
| 2096883 | KIT-REPAIR (AIR COMPRESSOR VALVE) | 1 | |
| 2096884 | KIT-REPAIR (AIR COMPRESSOR RING) | 1 | |
| 2096885 | KIT-REPAIR (AIR COMPRESSOR COVER) | 1 |
