150-1212 TURBOCHARGER GPS/N 7BJ1-67000

Group No: 150-1212
Part NumberPart NameQty
6I02171 BOLT (M8X1.25X20-MM)1
6I02202 GASKET1
6I02603 BOLT (M8X1.25X25-MM)2
6I05634 NUT (M10X1.5-THD)4
6I05725 BOLT (M8X1.25X20-MM)2
6I06546 BOLT (M10X1.5X25-MM)3
10044547 NUT (M8X1.25-THD)3
10048308 BOLT (M10X1.5X20-MM)2
5D10269 CLAMP-BAND2
101380510 BOLT (M8X1.25X90-MM)6
064305811 CLAMP-HOSE2
106891612 BOLT (M6X1X16-MM)2
114258313 STUD (M8X1.25X37-MM)3
114259014 CONNECTION1
124381515 BOLT (M8X1.25X16-MM)1
138204316 WASHER1
138206117 ADAPTER1
138206218 TUBE1
138206319 TUBE1
138206520 GASKET1
138207721 TURBOCHARGER GP1
140770022 ADAPTER1
164409623 MANIFOLD-INLET1
140770224 ELBOW1
140770325 GASKET-ELBOW1
140770426 HOSE1
140770727 ELBOW1
149423628 STUD (M10X1.5X37-MM)4
141982529 BRACKET1
143453430 HOSE1
143911231 GASKET2
144538032 GASKET-MANIFOLD1
144538333 MANIFOLD-EXHAUST1
146184034 NUT5
146426135 TUBE AS1
153495236 STUD5
147457737 BOLT8
1418584BOLT (M8X1.25X50-MM)4
1676920KIT-ACTUATOR MOUNTING1
1676921KIT-TURBOCHARGER1
