System And Components
187-5117 LINES GP-HYDRAULIC FILTERS/N 6HM413-UP; 4PN526-UP
Group No: 187-5117
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X5308 | 1 CAP-DUST | 1 | |
| 7X0871 | 2 TEE | 1 | |
| 5P9617 | 3 ADAPTER | 1 | |
| 3J1907 | 4 SEAL-O-RING | 1 | |
| 8C3446 | 5 VALVE-SAMPLING (HYDRAULIC OIL, FILTER INLET) | 1 | |
| 3J7354 | 6 SEAL-O-RING | 1 | |
| 6V8398 | 7 SEAL-O-RING | 5 | |
| 6V8721 | 8 ELBOW | 2 | |
| 2M9780 | 9 SEAL-O-RING | 3 | |
| 4P7581 | 10 CLIP (LADDER) | 3 | |
| 1873458 | 11 FILTER GP-OIL (HYDRAULIC) | 1 | |
| 1232311 | 12 HOSE AS | 1 | |
| 1G8758 | 13 HOSE AS | 1 | |
| 3S2093 | 14 STRAP-CABLE | 18 | |
| 1875070 | 15 HARNESS AS-WIRING (HYDRAULIC ALERT INDICATOR) | 1 | |
| 5P2321 | TERMINAL-FORK (14-GA TO 16-GA, NO. 6 SCREW) | 1 | |
| 5P4571 | TERMINAL-BLADE (14-GA TO 16-GA) | 2 | |
| 9D3127 | 16 BASE AS-INDICATOR LIGHT | 1 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 7N5876 | 17 LAMP (24-VOLT, 0.2-AMPERE) | 1 | |
| 9D2867 | 18 LENS-AMBER | 1 | |
| 2V3216 | 19 CLIP (LOOP) | 2 | |
| 6V8638 | 20 CONNECTOR | 1 | |
| 8T5465 | 21 ELBOW | 1 | |
| 6V9169 | 22 NUT (13/16-16-THD) | 1 | |
| 6V8397 | 23 SEAL-O-RING | 1 | |
| 6V9672 | 24 SCREW-MACHINE (M4X0.7X16-MM) | 2 | |
| 4B4863 | 25 WASHER (4.7X11X1.2-MM THK) | 2 | |
| 8T2659 | 26 LOCKNUT (M4X0.7-THD) | 2 |
