System And Components
465-5965 DOOR GP-CAB -LHS/N LXX1-UP
Group No: 465-5965
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V7636 | 1 PIN AS-SPRING | 1 | |
| 0909555 | 2 CLIP | 2 | |
| 1785572 | 3 SPACER-SPECIAL | 2 | |
| 2149186 | 4 BUTTON | 12 | |
| 2521862 | 5 HANDLE AS-PULL | 1 | |
| 2521863 | 6 GASKET | 1 | |
| 2692890 | 7 CLEVIS | 1 | |
| 2692892 | 8 PIN | 1 | |
| 2853692 | 9 SPACER-SPECIAL | 1 | |
| 3026392 | 10 PLUG | 1 | |
| 3631413 | 11 BUMPER | 1 | |
| 3716089 | 12 WINDOW GP-DOOR | 1 | |
| 3719511 | 13 HINGE AS | 1 | |
| 3725042 | 13A BUSHING | 2 | |
| 3719522 | 14 BRACKET | 1 | |
| 3727279 | 15 HANDLE AS | 1 | |
| 3727280 | 16 LATCH AS | 1 | |
| 3743585 | 17 END-YOKE ROD | 1 | |
| 3743586 | 18 PIN AS-SPRING | 1 | |
| 3770647 | 19 BRACKET | 1 | |
| 3792111 | 20 PLATE AS | 2 | |
| 8T4133 | NUT (M10X1.5-THD) | 2 | |
| 3833563 | 21 BELLCRANK AS | 1 | |
| 4180207 | 22 ROD | 1 | |
| 4180210 | 23 BUSHING | 1 | |
| 4265412 | 24 SEAL AS | 1 | |
| 4262831 | SEAL-DOOR | 1 | |
| 4265409 | PIN | 48 | |
| 4361542 | 25 PLUG-BUTTON | 6 | |
| 4390688 | 26 STRIKER AS | 1 | |
| 4460368 | 27 PLATE AS | 1 | |
| 4540658 | 28 SPRING-GAS (CAB DOOR, LH) | 1 | |
| 4620577 | 29 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 4626225 | 30 GLASS | 1 | |
| 4655966 | 31 DOOR AS-CAB (LH) | 1 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1840982 | SCREW-PAN HEAD (M6X1X16-MM) | 2 | |
| 4655987 | 32 TUBE AS | 1 | |
| 1146658 | 33 WASHER (6.5X17X1-MM THK) | 2 | |
| 1085471 | 34 CLEVIS | 1 | |
| 1199706 | 35 STUD-BALL | 2 | |
| 1219870 | 36 SCREW-MACHINE (M6X1X40-MM) | 4 | |
| 1272170 | 37 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 10 | |
| 1372255 | 38 BOLT (M8X1.25X8-MM) | 1 | |
| 1950936 | 39 INSERT-THREADED (M6X1-THD) | 3 | |
| 1953699 | 40 NUT (M8X1.25-THD) | 1 | |
| 2425206 | 41 SPACER (6.4X12.5X0.76-MM THK) | 3 | |
| 3220819 | 42 INSERT-THREADED (M10X1.5-THD) | 6 | |
| 3445673 | 43 NUT (M6X1-THD) | 4 | |
| 3463811 | 44 NUT-SQUARE | 1 | |
| 3E4353 | 45 WASHER-HARD (11X25X3-MM THK) | 5 | |
| 5C9553 | 46 BOLT (M6X1X16-MM) | 1 | |
| 5P4116 | 47 WASHER-HARD (8.8X20.5X2-MM THK) | 11 | |
| 6V5839 | 48 WASHER (11X21X2.5-MM THK) | 3 | |
| 8T4138 | 49 BOLT (M6X1X20-MM) | 2 | |
| 8T6902 | 50 CLIP | 1 | |
| 9X2038 | 51 WASHER (7X19X2-MM THK) | 1 | |
| 9X2039 | 52 SCREW-TRUSS HEAD (M10X1.5X35-MM) | 8 | |
| 9X2040 | 53 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 6 | |
| 9X2041 | 54 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 2 | |
| 9X2042 | 55 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 9X6421 | 56 RING-RETAINING | 1 | |
| 9X8256 | 57 WASHER (6.6X12X2-MM THK) | 2 |
