System And Components
465-5969 DOOR GP-CAB -LHS/N LXX1-UP
Group No: 465-5969
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V7636 | 1 PIN AS-SPRING | 1 | |
| 0909555 | 2 CLIP | 2 | |
| 1149284 | 3 BUMPER | 1 | |
| 1785572 | 4 SPACER-SPECIAL | 4 | |
| 2149186 | 5 BUTTON | 12 | |
| 2521862 | 6 HANDLE AS-PULL | 1 | |
| 2521863 | 7 GASKET | 1 | |
| 2692890 | 8 CLEVIS | 1 | |
| 2692892 | 9 PIN | 1 | |
| 2853692 | 10 SPACER-SPECIAL | 1 | |
| 3026392 | 11 PLUG | 1 | |
| 3463811 | 12 NUT-SQUARE | 1 | |
| 3672178 | 13 SPRING-GAS (CAB DOOR) | 1 | |
| 3716089 | 14 WINDOW GP-DOOR (LH) | 1 | |
| 3719511 | 15 HINGE AS | 2 | |
| 3725042 | BUSHING | 2 | |
| 3719522 | 16 BRACKET | 1 | |
| 3727279 | 17 HANDLE AS | 1 | |
| 3727280 | 18 LATCH AS | 1 | |
| 3743585 | 19 END-YOKE ROD | 1 | |
| 3743586 | 20 PIN AS-SPRING | 1 | |
| 3770647 | 21 BRACKET | 1 | |
| 3833563 | 22 BELLCRANK AS | 1 | |
| 4180207 | 23 ROD | 1 | |
| 4180210 | 24 BUSHING | 1 | |
| 4265412 | 25 SEAL AS | 1 | |
| 4262831 | SEAL-DOOR | 1 | |
| 4265409 | PIN | 48 | |
| 4361542 | 26 PLUG-BUTTON | 6 | |
| 4390688 | 27 STRIKER AS | 1 | |
| 4460368 | 28 PLATE AS | 1 | |
| 4607427 | 29 COVER-DOOR | 1 | |
| 4620577 | 30 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 4626225 | 31 GLASS (DOOR) | 1 | |
| 4655970 | 32 DOOR AS (LH) | 1 | |
| 4655987 | 33 TUBE AS | 1 | |
| 4758095 | 34 PLATE AS | 4 | |
| 8T4133 | NUT (M10X1.5-THD) | 2 | |
| 1146658 | 35 WASHER (6.5X17X1-MM THK) | 2 | |
| 1085471 | 36 CLEVIS | 1 | |
| 1199706 | 37 STUD-BALL | 2 | |
| 1219870 | 38 SCREW-MACHINE (M6X1X40-MM) | 4 | |
| 1272170 | 39 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 14 | |
| 1372255 | 40 BOLT (M8X1.25X8-MM) | 1 | |
| 1950936 | 41 INSERT-THREADED (M6X1-THD) | 3 | |
| 1953699 | 42 NUT (M8X1.25-THD) | 1 | |
| 2425206 | 43 SPACER (6.4X12.5X0.76-MM THK) | 3 | |
| 3220819 | 44 INSERT-THREADED (M10X1.5-THD) | 6 | |
| 3445673 | 45 NUT (M6X1-THD) | 4 | |
| 3E4353 | 46 WASHER-HARD (11X25X3-MM THK) | 5 | |
| 5C9553 | 47 BOLT (M6X1X16-MM) | 1 | |
| 5P4116 | 48 WASHER-HARD (8.8X20.5X2-MM THK) | 15 | |
| 6V5839 | 49 WASHER (11X21X2.5-MM THK) | 3 | |
| 8T4138 | 50 BOLT (M6X1X20-MM) | 2 | |
| 8T6902 | 51 CLIP | 1 | |
| 9X2038 | 52 WASHER (7X19X2-MM THK) | 1 | |
| 9X2039 | 53 SCREW-TRUSS HEAD (M10X1.5X35-MM) | 8 | |
| 9X2040 | 54 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 6 | |
| 9X2041 | 55 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 2 | |
| 9X2042 | 56 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 9X6421 | 57 RING-RETAINING | 1 | |
| 9X8256 | 58 WASHER (6.6X12X2-MM THK) | 2 |
