System And Components
391-5327 DOOR GP-CAB -LHS/N SXS1-UP
Group No: 391-5327
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V7636 | 1 PIN AS-SPRING | 1 | |
| 0857329 | 2 SPACER (9X19X30-MM THK) | 2 | |
| 1085471 | 3 CLEVIS | 1 | |
| 1108152 | 4 HANDLE AS-PULL | 1 | |
| 1785572 | 5 SPACER-SPECIAL | 4 | |
| 1953699 | 6 NUT (M8X1.25-THD) | 1 | |
| 2149186 | 7 BUTTON | 12 | |
| 2425206 | 8 SPACER (6.4X12.5X0.76-MM THK) | 3 | |
| 2521862 | 9 HANDLE AS-PULL | 1 | |
| 2521863 | 10 GASKET | 1 | |
| 2692890 | 11 CLEVIS | 1 | |
| 2692892 | 12 PIN | 1 | |
| 2853692 | 13 SPACER-SPECIAL | 1 | |
| 3026392 | 14 PLUG | 1 | |
| 3220819 | 15 INSERT-THREADED (M10X1.5-THD) | 5 | |
| 3463811 | 16 NUT-SQUARE | 1 | |
| 3664535 | 17 DOOR AS-CAB (LH) | 1 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1840982 | SCREW-PAN HEAD (M6X1X16-MM) | 2 | |
| 3716088 | 18 GLASS | 1 | |
| 3719511 | 19 HINGE AS | 2 | |
| 3725042 | BUSHING | 2 | |
| 3719520 | 20 TUBE AS | 1 | |
| 4758095 | 21 PLATE AS | 2 | |
| 3833563 | 22 BELLCRANK AS | 1 | |
| 3923980 | 23 WINDOW GP-DOOR (LH) | 1 | |
| 4759824 | 24 SPRING-GAS (DOOR) | 1 | |
| 4460368 | 25 PLATE AS | 1 | |
| 4180207 | 26 ROD | 1 | |
| 4180210 | 27 BUSHING | 1 | |
| 4221675 | 28 KNOB | 2 | |
| 4232603 | 29 LATCH AS | 1 | |
| 4265412 | 30 SEAL AS | 1 | |
| 4262831 | SEAL-DOOR | 1 | |
| 4265409 | PIN | 48 | |
| 4361542 | 31 PLUG-BUTTON | 4 | |
| 4390688 | 32 STRIKER AS | 1 | |
| 0310249 | 33 LOCKNUT (10-24-THD) | 1 | |
| 1053486 | 34 BOLT-SOCKET HEAD (M6X1X50-MM) | 2 | |
| 1178929 | 35 WASHER (6.6X22X2-MM THK) | 1 | |
| 1272170 | 36 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 10 | |
| 1372255 | 37 BOLT (M8X1.25X8-MM) | 1 | |
| 1950936 | 38 INSERT-THREADED (M6X1-THD) | 5 | |
| 3E4353 | 39 WASHER-HARD (11X25X3-MM THK) | 4 | |
| 5C9553 | 40 BOLT (M6X1X16-MM) | 1 | |
| 5P4116 | 41 WASHER-HARD (8.8X20.5X2-MM THK) | 11 | |
| 6V5839 | 42 WASHER (11X21X2.5-MM THK) | 2 | |
| 7M9910 | 43 SCREW-MACHINE (10-24X1-IN) | 1 | |
| 8T3991 | 44 SCREW-BUTTON HEAD (M6X1X20-MM) | 4 | |
| 8T4138 | 45 BOLT (M6X1X20-MM) | 2 | |
| 8T6902 | 46 CLIP | 1 | |
| 9X2039 | 47 SCREW-TRUSS HEAD (M10X1.5X35-MM) | 8 | |
| 9X2040 | 48 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 2 | |
| 9X2041 | 49 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 2 | |
| 9X8256 | 50 WASHER (6.6X12X2-MM THK) | 2 | |
| 9X6421 | 51 RING-RETAINING | 1 | |
| 5013976 | 52 BRACKET AS | 1 | |
| 3915346 | 53 COVER-DOOR | 1 | |
| 2061667 | 54 CLIP (TRIM) | 6 | |
| 4869155 | 55 BUMPER AS | 1 | |
| 9X6155 | 56 BOLT-SOCKET HEAD (M6X1X16.7-MM) | 3 | |
| 8T8549 | 57 LOCKNUT (M12X1.75-THD) | 1 |
