System And Components
415-8192 LINES GP-AFTERCOOLER AIRS/N ENE1-UP
Group No: 415-8192
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4158191 | 1 TUBE | 1 | |
| 4158193 | 2 TUBE | 1 | |
| 4158194 | 3 TUBE | 1 | |
| 3E4096 | 4 CAP | 10 | |
| 3094069 | 5 HOSE | 2 | |
| 3649846 | 6 BRACKET AS | 1 | |
| 4158196 | 7 HOSE | 1 | |
| 4158198 | 8 HOSE-ELBOW | 1 | |
| 4158199 | 9 HOSE | 1 | |
| 4323596 | 10 CLAMP | 1 | |
| 2094578 | 11 CLAMP-T BOLT | 8 | |
| 2094580 | 12 CLAMP-T BOLT | 1 | |
| 2126934 | 13 CLAMP-T BOLT | 1 | |
| 3251242 | 14 CLIP | 1 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4222 | 17 WASHER-PLATED (11X32X2.5-MM THK) | 4 | |
| 8T4196 | 18 BOLT (M10X1.5X35-MM) | 3 | |
| 5633694 | 19 BRACKET AS | 1 | |
| 7X7729 | 20 WASHER (11X25X3-MM THK) | 3 | |
| 9X2646 | 21 CLIP (SLOT) | 1 | |
| 9X2647 | 22 CLIP (TAB) | 1 |
