System And Components
379-0399 DOOR GP-CABS/N RTL1-UP
Group No: 379-0399
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8Y6386 | 1 SEAL-HANDLE | 1 | |
| 9C9785 | 2 BUMPER | 2 | |
| 2149186 | 3 BUTTON | 12 | |
| 2583764 | 4 STRIKER AS | 1 | |
| 3433176 | 5 BUSHING | 2 | |
| 3463811 | 6 NUT-SQUARE | 1 | |
| 3790375 | 7 PLATE | 1 | |
| 3790384 | 8 INSULATION | 1 | |
| 3790390 | 9 GLASS | 1 | |
| 4751957 | 10 BRACKET AS | 2 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 3790400 | 11 DOOR AS | 1 | |
| 8T5413 | STUD-WELD (M10X1.5X25-MM) | 4 | |
| 3790405 | 12 DRIVE AS-WINDOW | 1 | |
| 3790406 | 13 INSULATION | 1 | |
| 3790408 | 14 GLASS | 1 | |
| 4243507 | 15 HANDLE AS | 1 | |
| 8Y4501 | SPRING-HANDLE | 1 | |
| 4243509 | 16 LATCH AS | 1 | |
| 4246353 | 17 COVER AS | 1 | |
| 4246354 | 18 COVER-HANDLE | 1 | |
| 4256539 | 19 HINGE AS | 3 | |
| 3725042 | 19A BUSHING | 2 | |
| 4361542 | 20 PLUG-BUTTON | 2 | |
| 4415764 | 21 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 4460368 | 22 PLATE AS | 1 | |
| 4477890 | 23 CUSHION AS | 1 | |
| 1146658 | 24 WASHER (6.5X17X1-MM THK) | 12 | |
| 1757141 | 25 NUT-HEX FLANGE (M10X1.5-THD) | 4 | |
| 1548079 | 26 NUT-RETAINER | 1 | |
| 2046102 | 27 WASHER-HARD (4.45X9.52X1-MM THK) | 1 | |
| 2227892 | 28 SWITCH AS-ROCKER (24-VOLT)(POWER WINDOW) | 1 | |
| 2253109 | 29 SCREW-TRUSS HEAD (M4X0.7X14-MM) | 1 | |
| 1728591 | 30 NUT-CLIP (M6X1-THD) | 10 | |
| 5P0537 | 31 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 6V5839 | 32 WASHER (11X21X2.5-MM THK) | 2 | |
| 8T4121 | 33 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 8T4142 | 34 BOLT-FLANGE HEAD (M5X0.8X12-MM) | 4 | |
| 9X2040 | 35 SCREW-TRUSS HEAD (M10X1.5X25-MM) | 20 | |
| 9X2045 | 36 SCREW-TRUSS HEAD (M6X1X20-MM) | 12 | |
| 6V7357 | 37 BOLT (M6X1X25-MM) | 8 | |
| 9X2125 | 38 BOLT-LOCKING (M10X1.5X25-MM) | 2 | |
| 4606331 | 39 SEAL-WINDOW | 1 | |
| 3202978 | 40 SEAL (54-CM EACH) | ||
| 5252188 | 41 SEAL-BULK (463-CM) |
