375-4645 HOUSING GP-FRONTS/N E7A1-UP

Group No: 375-4645
Part NumberPart NameQty
6I04541 BOLT (M10X1.5X70-MM)6
7C46162 BOLT (M12X1.75X45-MM)1
06761793 DOWEL1
10037514 BOLT (M8X1.25X65-MM)5
10138955 BOLT (M8X1.25X35-MM)2
13310116 WASHER1
23236667 WASHER-THRUST1
27730128 GASKET-COVER1
27730139 SEAL1
291651710 PLATE1
381925211 GEAR-IDLER (73-TEETH)1
416123412 CASE-GEAR1
418768413 GEAR-IDLER (44-TEETH)1
6I021714 BOLT (M8X1.25X20-MM)6
6I025415 BOLT (M8X1.25X30-MM)3
6I026016 BOLT (M8X1.25X25-MM)9
6I064517 BOLT (M8X1.25X25-MM)4
425710318 GEAR (68-TEETH)1
291652119 TUBE1
291652220 CLIP2
291652321 COVER-FRONT1
291652422 GASKET1
