System And Components
493-2589 RADIATOR & AFTERCOOLER GPS/N LCR1-UP
Group No: 493-2589
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1213307 | 1 MOUNT AS-RESILIENT | 2 | |
| 2916737 | 2 LATCH AS | 1 | |
| 4165237 | 3 CORE AS-RADIATOR | 1 | |
| 3355462 | PIN | 8 | |
| 4165238 | 4 CORE AS-AFTERCOOLER | 1 | |
| 4771668 | 5 HINGE AS | 1 | |
| 5004032 | 6 CORE AS-CONDENSER | 1 | |
| 3178141 | MOUNT | 4 | |
| 5036025 | 7 CORE AS-OIL COOLER | 1 | |
| 3445675 | 8 NUT (M10X1.5-THD) | 5 | |
| 5C2890 | 9 NUT (M6X1-THD) | 4 | |
| 5V8780 | 10 KNOB | 1 | |
| 7X0579 | 11 WASHER-HARD (8.8X25.5X2-MM THK) | 2 | |
| 7X7729 | 12 WASHER (11X25X3-MM THK) | 8 | |
| 8T4195 | 13 BOLT (M10X1.5X30-MM) | 3 | |
| 8T7547 | 14 BOLT (M8X1.25X30-MM) | 2 | |
| 9X8256 | 15 WASHER (6.6X12X2-MM THK) | 4 |
