System And Components
365-0165 MOUNTING GP-AIR CLEANERS/N LCR1-UP
Group No: 365-0165
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2609210 | 1 PLUG | 1 | |
| 3311134 | 2 SENSOR GP-PRESSURE (AIR INLET) | 1 | |
| 3400508 | 3 SENSOR GP-TEMPERATURE (AIR INLET) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2566453 | SENSOR-TEMPERATURE (2-PIN)(AIR INLET) | 1 | |
| 3650105 | 4 SHIELD AS | 1 | |
| 1728591 | NUT-CLIP (M6X1-THD) | 1 | |
| 3650145 | 5 BRACKET | 1 | |
| 3650146 | 6 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3650153 | 7 AIR CLEANER GP | 1 | |
| 2118073 | 8 CAP-PROTECTION | 2 | |
| 2287100 | 9 SEAL-O-RING | 1 | |
| 5P4116 | 10 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 7X0579 | 11 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 7X7729 | 12 WASHER (11X25X3-MM THK) | 4 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4189 | 14 BOLT (M8X1.25X20-MM) | 10 | |
| 8T4196 | 15 BOLT (M10X1.5X35-MM) | 1 |
