System And Components
518-3281 PRECLEANER GPS/N LCR1-UP
Group No: 518-3281
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 1440367 | 2 CLAMP-HOSE | 2 | |
| 2062423 | 3 SADDLE-MOUNTING | 1 | |
| 2130985 | 4 GROMMET | 1 | |
| 2905664 | 5 STRAP-CABLE | 1 | |
| 4560560 | 6 PRECLEANER GP-CAB AIR | 1 | |
| 4596697 | 7 HARNESS AS-WIRING (DEMAND FAN) | 1 | |
| 5026983 | 8 PLATE | 1 | |
| 5183282 | 9 BRACKET AS | 1 | |
| 5183285 | 10 HOSE | 1 | |
| 5183286 | 11 COVER AS | 1 | |
| 1416518 | 12 SPACER (13.5X30X10-MM THK) | 2 | |
| 2D0388 | 13 GROMMET (25.4-MM ID) | 2 | |
| 2V8260 | 14 GROMMET | 1 | |
| 5C9553 | 15 BOLT (M6X1X16-MM) | 2 | |
| 6V7357 | 16 BOLT (M6X1X25-MM) | 2 | |
| 7X7729 | 17 WASHER (11X25X3-MM THK) | 6 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4196 | 19 BOLT (M10X1.5X35-MM) | 4 | |
| 9X2038 | 20 WASHER (7X19X2-MM THK) | 4 | |
| 9X2043 | 21 SCREW-TRUSS HEAD (M6X1X14-MM) | 2 | |
| 9X8256 | 22 WASHER (6.6X12X2-MM THK) | 2 | |
| 5P5637 | 23 SEAL (0.4-M EACH) | ||
| 5P5637 | 23A SEAL (0.2-M EACH) |
