System And Components
518-3281 PRECLEANER GPS/N LCR1-UP
Group No: 518-3281
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4196 | 1 BOLT (M10X1.5X35-MM) | 4 | |
| 3S2093 | 2 STRAP-CABLE | 4 | |
| 7X7729 | 3 WASHER (11X25X3-MM THK) | 6 | |
| 2062423 | 4 SADDLE-MOUNTING | 1 | |
| 2130985 | 5 GROMMET | 1 | |
| 2905664 | 6 STRAP-CABLE | 1 | |
| 1416518 | 7 SPACER (13.5X30X10-MM THK) | 2 | |
| 1440367 | 8 CLAMP-HOSE | 2 | |
| 2V8260 | 9 GROMMET | 1 | |
| 3E8020 | 10 SCREW-TRUSS HEAD (M6X1X25-MM) | 2 | |
| 4596697 | 11 HARNESS AS-WIRING (DEMAND FAN) | 1 | |
| 5183285 | 12 HOSE | 1 | |
| 5183286 | 13 COVER AS | 1 | |
| 5408689 | 14 PRECLEANER GP-CAB AIR | 1 | |
| 5578722 | 15 BRACKET AS | 1 | |
| 7T1099 | LINK | 1 | |
| 9X2038 | 16 WASHER (7X19X2-MM THK) | 4 | |
| 9X2041 | 17 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 2 | |
| 9X2043 | 18 SCREW-TRUSS HEAD (M6X1X14-MM) | 2 | |
| 5P5637 | 20 SEAL (0.4-M EACH) | ||
| 5P5637 | 20A SEAL (0.2-M EACH) |
