System And Components
377-2411 LINES GP-ENGINE OILS/N H6C1-UP
Group No: 377-2411
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W1053 | 1 PLUG | 1 | |
| 4W0530 | 2 RING-RETAINING | 2 | |
| 4W0531 | 3 RETAINER | 4 | |
| 6B9202 | 4 SPRING | 2 | |
| 7C9597 | 5 FLANGE | 5 | |
| 7N7697 | 6 PLUNGER AS (SEQUENCE VALVE) | 2 | |
| 7M1808 | DOWEL | 1 | |
| 8N2929 | 7 COVER | 2 | |
| 1539481 | 8 CLAMP AS | 4 | |
| 1539963 | 9 RING | 2 | |
| 2377623 | 10 SEAL-O-RING | 5 | |
| 3586203 | 11 ELBOW | 1 | |
| 3586204 | 12 ADAPTER | 1 | |
| 3586227 | 13 BRACKET | 1 | |
| 3594123 | 14 ADAPTER (TURBOCHARGER OIL) | 1 | |
| 3676343 | 15 BRACKET AS | 1 | |
| 3688533 | 16 TUBE AS | 1 | |
| 3688534 | 17 TUBE AS | 1 | |
| 3688535 | 18 PLATE AS | 1 | |
| 0336031 | 19 SEAL-O-RING | 5 | |
| 0619456 | 20 SEAL-O-RING | 2 | |
| 0L1143 | 21 BOLT (3/8-16X2.5-IN) | 4 | |
| 0L2070 | 22 BOLT (3/8-16X2.25-IN) | 4 | |
| 0S1588 | 23 BOLT (3/8-16X1.25-IN) | 4 | |
| 0S1590 | 24 BOLT (3/8-16X2-IN) | 2 | |
| 0S1594 | 25 BOLT (3/8-16X1-IN) | 6 | |
| 0S1619 | 26 BOLT (3/8-16X3-IN) | 4 | |
| 1A2029 | 27 BOLT (3/8-16X1.125-IN) | 7 | |
| 2287097 | 28 SEAL-O-RING | 1 | |
| 3B1915 | 29 BOLT (3/8-16X1.375-IN) | 3 | |
| 5M2894 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P4892 | 31 SEAL-O-RING | 2 | |
| 6V1581 | 32 CLIP (SLOT) | 1 | |
| 6V1582 | 33 CLIP (TAB) | 1 | |
| 6V4368 | 34 SEAL-O-RING | 2 | |
| 6V4589 | 35 SEAL-O-RING | 1 | |
| 6V5048 | 36 SEAL-O-RING | 1 | |
| 8C3445 | 37 CAP-DUST | 1 | |
| 8C3446 | 38 VALVE-SAMPLING | 1 | |
| 8S9191 | 39 BOLT (3/8-16X4-IN) | 4 | |
| 8T6762 | 40 PLUG-PIPE (1/2-14-THD) | 1 | |
| 9S4190 | 41 PLUG-O-RING (7/8-14-THD) | 1 | |
| 9S8752 | 42 NUT-FULL (3/8-16-THD) | 7 | |
| 9X6458 | 43 WASHER-HARD (10.2X22.5X3-MM THK) | 22 |
