463-4168 LINES GP-PRELUBRICATION -PUMPS/N H6C1-UP

Group No: 463-4168

Part Number	Part Name	Qty
2G6303	1 SEAL	1
2G6304	2 STRAINER AS	1
2L8076	3 TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW)	1
3N6935	4 VALVE-CHECK	1
3R1059	5 FLANGE	1
5P1475	6 TERMINAL-FORK (14-GA TO 16-GA, NO. 8 SCREW)	2
3453922	7 ADAPTER AS	1
3K0360	SEAL-O-RING	1
3453921	ADAPTER	1
1259993	8 TERMINAL-FORK (14-GA TO 16-GA, NO. 6 SCREW)	2
2224533	9 RELAY AS (24-VOLT)(PRELUBRICATION)	1
3083015	10 HOSE AS	1
3579033	11 CLAMP	1
3596007	12 BRACKET AS	1
9F6445	NUT-WELD (1/4-20-THD)	1
3596014	13 HARNESS AS-WIRING (PRELUBRICATION PUMP)	1
3687967	14 HARNESS AS-WIRING (PRELUBRICATION PUMP)	1
4190732	15 HOSE AS	1
4255935	16 TUBE AS	1
4564876	17 PUMP GP-PRELUBRICATION	1
4677218	18 PLATE	1
1653931	19 BOLT (3/8-16X1.75-IN)	2
0S1587	20 BOLT (1/2-13X1.75-IN)	1
1F7958	21 NUT-FULL (1/2-13-THD)	1
1S0996	22 CLIP	2
2186854	23 WASHER (5.31X9X1.1-MM THK)	2
2B0941	24 SPACER (10.5X19X19-MM THK)	4
2T1922	25 ELBOW	3
2T2396	26 ELBOW	1
1180911	27 TEE-O-RING PORT	1
3B1915	28 BOLT (3/8-16X1.375-IN)	1
3K0360	29 SEAL-O-RING	1
4B1227	30 SCREW-MACHINE (10-24X3/8-IN)	3
5M2894	31 WASHER-HARD (10.2X18.5X2.5-MM THK)	2
5P1075	32 WASHER-HARD (10.2X22.5X3-MM THK)	4
5P5846	33 SEAL-O-RING	1
5P8245	34 WASHER-HARD (13.5X25.5X3-MM THK)	2
5S7382	35 BOLT (3/8-16X1.375-IN)	2
6V1581	36 CLIP (SLOT)	1
6V1582	37 CLIP (TAB)	1
6V6782	38 CLIP (SLOT)	1
6V6783	39 CLIP (TAB)	1
6V8398	40 SEAL-O-RING	4
6V8801	41 NUT (3/8-16-THD)	4
8B2664	42 BUSHING-REDUCER	1
8H3127	43 BOLT (1/4-20X0.75-IN)	1
8T2501	44 BOLT (3/8-16X2-IN)	4
8T4896	45 WASHER-HARD (10.2X18.5X2.5-MM THK)	8
9S8752	46 NUT-FULL (3/8-16-THD)	1
9X6458	47 WASHER-HARD (10.2X22.5X3-MM THK)	2
7X0860	48 BOLT (3/8-16X1.5-IN)	2
2385080	49 SEAL-O-RING	1
3603693	50 PLUG (3/4-16-THD)	1
