System And Components
377-2426 MANIFOLD GP-EXHAUSTS/N H6C1-UP; N1S1-UP
Group No: 377-2426
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1494312 | 1 WASHER (17X30X3.5-MM THK) | 24 | |
| 3402663 | 2 BELLOWS AS | 1 | |
| 3428371 | 3 BRACKET | 1 | |
| 3519250 | 4 MANIFOLD-EXHAUST | 1 | |
| 3519427 | 5 COVER | 2 | |
| 3565013 | 6 ELBOW | 1 | |
| 3565014 | 7 ELBOW | 1 | |
| 4549486 | 8 BRACKET (LH) | 1 | |
| 4549483 | 9 BRACKET (RH) | 1 | |
| 4549488 | 10 PLATE | 2 | |
| 3565020 | 11 BRACKET AS | 1 | |
| 3568647 | 12 SEAL | 38 | |
| 3568648 | 13 SEAL | 16 | |
| 3721005 | 14 MANIFOLD-EXHAUST | 16 | |
| 3809647 | 15 BELLOWS AS | 18 | |
| 3844306 | 16 GASKET | 2 | |
| 0S1590 | 17 BOLT (3/8-16X2-IN) | 4 | |
| 1077954 | 18 SPACER (10.2X22X8-MM THK) | 520 | |
| 1626466 | 19 BOLT-12 POINT HEAD (5/8-11X2.75-IN) | 12 | |
| 1A0168 | 20 BOLT (1/2-13X7.5-IN) | 6 | |
| 3767739 | 21 BOLT (3/8-16X2.5-IN) | 228 | |
| 3E6916 | 22 NUT-FULL (3/8-16-THD) | 228 | |
| 5P8245 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 6L3143 | 24 BOLT-HIGH TEMPERATURE (1/2-13X3-IN) | 6 | |
| 6L8550 | 25 BOLT-HIGH TEMPERATURE (3/8-16X2.25-IN) | 64 | |
| 6V3631 | 26 NUT-FULL (1/2-13-THD) | 14 | |
| 6V4605 | 27 LOCKNUT (5/8-11-THD) | 12 | |
| 6V5766 | 28 BOLT (1/2-13X2.5-IN) | 4 | |
| 0S1587 | 29 BOLT (1/2-13X1.75-IN) | 4 | |
| 7D1649 | 30 WASHER-HARD (13.5X32X5-MM THK) | 16 | |
| 7F9504 | 31 PLUG-PIPE (1/4-18-THD) | 2 | |
| 9S1366 | 32 BOLT (1/2-13X2.5-IN) | 4 | |
| 9X6458 | 33 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 2B0947 | 34 BOLT (1/2-13X2.25-IN) | 2 | |
| 1S4305 | 35 SPACER (0.531X1X0.56-IN THK) | 4 | |
| 5238667 | 36 BRACKET | 1 | |
| 5238668 | 37 BRACKET | 1 |
